COOLING SYSTEM

HOSE - BELL HOUSING HOSE - BELL HOUSING

32-8M0109048 32-8M0062102
3/4 in. (19 mm) I.D. formed hose Fits Bravo transom (s/n 2A416416‑2A514802)
Fits MR, Alpha One & Gen II
HOSE - BELL HOUSING
HOSE - BELL HOUSING

32- 43437
NLA ‑ Order 32‑8M0090859
Fits Bravo transom
HOSE - BELL HOUSING MERCURY® MERCRUISER®
32-8M0124395
Fits Bravo transom (s/n 2A514803 and up)

32-8M0090859
Hose kit replaces 32‑43437
Fits Bravo transom

HOSE CHART - WATER

2000 & newer model engines with a water drain system are not included in this chart due to these various additional hoses which would be too
complicated to include in these charts.

Water Hoses ‑ Engine Supply

Model CID/Litre Cyl. Year Range Serial # Range Circ. W/P Pump to Transom to (T'stat (Transom or Oil Cooler to Cooler Cooler to T'stat
T'stat Hsg Hsg or Seawater Seawater Pump) to Hsg
Pump) Oil Cooler
120 153/2.5L I/L 4 1968 - 1978 2324347 - 5192048 32-8M0071007 32- 47642 N/A N/A N/A
120 153/2.5L I/L 4 1979 - 1982 5192049 - 6229717 32-8M0071007 32- 47642 N.L.A. N/A N.L.A.
120 153/2.5L I/L 4 1983 - 1986 6229718 - 0B531853 32-8M0071007 32- 47642(1) N.L.A.(1) N/A N.L.A.(1)
120 153/2.5L I/L 4 1983 - 1986 6229718 - 0B531853 32-8M0071007 32-8M0062634(2) N.L.A.(2) N/A N.L.A.(2)
2.5L 153/2.5L I/L 4 1987 - 1989 0B531854 - 0C853255 32-8M0071007 32-8M0062634 N.L.A. N/A N.L.A.

140 (4 cyl.) 181/3.0L I/L 4 1968 - 1978 2508261 - 5157668 32-8M0071007 32- 47642 N/A N/A N/A
140 (4 cyl.) 181/3.0L I/L 4 1979 - 1982 5157669 - 6229717 32-8M0071007 32- 47642 N.L.A. N/A N.L.A.
140 (4 cyl.) 181/3.0L I/L 4 1983 - 1986 6229718 - 0B450800 32-8M0071007 32- 47642(1) N.L.A.(1) N/A N.L.A.(1)
140 (4 cyl.) 181/3.0L I/L 4 1983 - 1986 6229718 - 0B450800 32-8M0071007 32-8M0062634(2) N.L.A.(2) N/A N.L.A.(2)
3.0L 181/3.0L I/L 4 1987 - 1989 0B450801 - 0C856558 32-8M0071007 32-8M0062634 N.L.A. N/A N.L.A.
