Page 872 - Quicksilver Product Guide (2020) - 8M0163242

EXTERNAL ENGINE

ENGINE DRIVE PLATE

860125T
Fits MIE & Tow Sports GM V‑8 engines

ENGINE COUPLER CHART

Engine Couplers
Model CID/ #Cyl Year Range Serial # Range Engine Coupler
100 Vazer 98/ L 4 2007 - 2009 1A035000 - 1A036006 N.L.A.
MERCURY® MERCRUISER®
110 153/ L 4 1963 - 1966 1537370 - 2044033 76850A 2
120 153/ L 4 1964 - 1982 1666601 - 6229717 76850A 2
120 153/ L 4 1983 - 1986 6229718 - 0B531853 76850A 2(9)
120 153/ L 4 1983 - 1986 6229718 - 0B531853 12632A 7(3)
2.5L 153/ L 4 1987 - 1989 0B531854 - 0C853255 76850A 2(9)
2.5L 153/ L 4 1987 - 1989 0B531854 - 0C853255 12632A 7(3)

140 181/ L 4 1968 - 1982 2508261 - 6229717 76850A 2
140 181/ L 4 1983 - 1986 6229718 - 0B450800 76850A 2(9)
140 181/ L 4 1983 - 1986 6229718 - 0B450800 12632A 7(3)
3.0L 181/ L 4 1987 - 1989 0B450801 - 0C856558 76850A 2(9)
3.0L 181/ L 4 1987 - 1989 0B450801 - 0C856558 12632A 7(3)
3.0L 181/ L 4 1990 - 1994 0C856559 - 0F603999 12632A 7
3.0L 181/ L 4 1998 - 2019 0L097000 and up 18643A 5
3.0L MPI 181/ L 4 2008 - 2019 1A072812 and up 18643A 5
3.0LX 181/ L 4 1990 - 1993 0C856559 - 0F000000 12632A 7
3.0LX 181/ L 4 1994 - 1998 0F000001 - 0L096999 12632A 6

165 224/ L 4 1987 0B434941 - 0B774251 97432A 2
170 224/ L 4 1985 - 1986 6916779 - 0B434940 97432A 2
180 224/ L 4 1987 0B436391 - 0B775248 97432A 2
190 224/ L 4 1985 - 1986 6916779 - 0B436390 97432A 2
3.7L 224/ L 4 1988 - 1989 0B774252 and up 97432A 2
3.7LX 224/ L 4 1983 - 1989 0B775249 and up 97432A 2
470 224/ L 4 1976 - 1982 4208730 - 6218036 69354A 2
470 224/ L 4 1983 - 1984 6218037 - 6916778 97432A 2
470 MIE 224/ L 4 1980 - 1981 5520115 - 6218036 N.L.A.
485 224/ L 4 1980 - 1982 5685394 - 6218036 69354A 2
488 224/ L 4 1983 - 1984 6170297 - 6916779 97432A 2

140 (6 cyl.) 194/ L 6 1963 1538930 - 1664117 76850A 2
150 230/ L 6 1964 - 1966 1664118 - 2048046 76850A 2
160 250/ L 6 1967 - 1969 2048022 - 2770031 76850A 2

Quicksilver Product Guide 863
