Page 912 - Quicksilver Product Guide (2020) - 8M0163242
P. 912
INTERNAL ENGINE
Model CID/ # Cyl Year Serial # Range Camshaft Bearings Camshaft Lifter Push Rod - Exhaust Push Rod - Intake
Range -Std.
898 (LH) 305/ V-8 1977 - 1984 4762210 - 6899057 23- 85674 431- 5943 8M0160608 99948 99948
898 (RH) 305/ V-8 1977 - 1982 4762210 - 6218461 23- 85674 N.L.A. 8M0160608 99948 99948
225 (LH) (GM) 327/ V-8 1963 - 1969 1539620 - 2694014 23- 85674 N.L.A. 8M0160608 99948 99948
225 (RH) (GM) 327/ V-8 1963 - 1967 1539620 - 2399397 23- 85674 N.L.A. 8M0160608 99948 99948
250 (LH) 327/ V-8 1968 - 1969 2314301 - 2639854 23- 85674 N.L.A. 8M0160608 99948 99948
250 (RH) 327/ V-8 1968 - 1969 2314301 - 2639854 23- 85674 N.L.A. 8M0160608 99948 99948
250 350/ V-8 1977 4768000 - 4908849 23- 85674 431- 5943 8M0160608 99948 99948
255 (GM) 350/ V-8 1975 - 1976 4175500 - 4767999 23- 85674 431- 5943 8M0160608 99948 99948
255 MIE (LH) (GM) 350/ V-8 1975 - 1980 4175500 - 5907057 23- 85674 431- 5943 8M0160608 99948 99948
255 MIE (RH) (GM) 350/ V-8 1975 - 1980 4175500 - 5907057 23- 85674 N.L.A. 8M0160608 99948 99948
260 350/ V-8 1978 - 1987 4908850 - 0B773304 23- 85674 431- 5943 8M0160608 99948 99948
260 MIE (LH) 350/ V-8 1981 - 1987 5907058 - 0B788151 23- 85674 431- 5943 8M0160608 99948 99948
260 MIE (RH) 350/ V-8 1981 - 1987 5907058 - 0B788151 23- 85674 N.L.A. 8M0160608 99948 99948
270 (LH) 350/ V-8 1969 - 1972 2851074 - 3077735 23- 85674 N.L.A. 8M0160608 99948 99948
270 (RH) 350/ V-8 1969 - 1972 2851074 - 3077735 23- 85674 N.L.A. 8M0160608 99948 99948
280 350/ V-8 1975 - 1976 4176250 - 4770199 23- 85674 N.L.A. 8M0160608 99948 99948
300 350/ V-8 1985 - 1986 6668677 - 0B430367 23- 85674 N.L.A. 8M0160608 99948 99948
320 EFI 350/ V-8 1987 - 1989 0A543604 - 0C622418 23- 85674 N.L.A. 8M0160608 99948 99948 MERCURY® MERCRUISER®
350 Mag Alpha 350/ V-8 1986 - 1991 0A635178 - 0D617327 23- 85674 431- 5943 8M0160608 99948 99948
350 Mag Alpha 350/ V-8 1992 - 1995 0D617328 - 0F600999 23- 85674 431-811658 17340T 17339 17339
350 Mag Alpha 350/ V-8 1996 - 1997 0F601000 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag Alpha EFI (Gen +) 350/ V-8 1996 - 1997 0F800300 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag Bravo MPI 350/ V-8 1995 0F415189 - 0K999999 23- 85674 431-811658 17340T 17339 17339
350 Mag Bravo MPI (Gen +) 350/ V-8 1996 - 1997 0F602000 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag EFI Ski 350/ V-8 1994 - 1996 0F215561 - 0F820706 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag EFI Ski (Gen +) 350/ V-8 1996 - 1997 0F820707 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI (Gen +) 350/ V-8 1998 - 2004 0L010019 - 0W310000 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI 350/ V-8 2004 - 2019 0W310000 and up 23- 85674 431-866022T 17340T 1 17339 1 17339 1
350 Mag MPI Horizon (Gen +) 350/ V-8 2002 - 2004 0M300000 - 0W309999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI Horizon (Gen +) 350/ V-8 2004 - 2007 0W310000 - 1A299999 23- 85674 431-866022T 17340T 1 17339 1 17339 1
350 Mag MPI Horizon MIE (Gen +) 350/ V-8 1999 - 2004 0L304700 - 0W309999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI Horizon MIE (Gen +) 350/ V-8 2004 - 2007 0W310000 - 1A089999 23- 85674 431-866022T 17340T 1 17339 1 17339 1
350 Mag MPI MIE (Gen +) 350/ V-8 1998 - 2004 0L002008 - 0W309999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI MIE (Gen +) 350/ V-8 2004 - 2007 0W310000 - 1A089999 23- 85674 431-866022T 17340T 1 17339 1 17339 1
350 Mag MPI Ski 350/ V-8 1995 - 1996 0F350583 - 0F799999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag MPI Ski (Gen +) 350/ V-8 1998 - 2007 0L002600 - 1A089999 23- 85674 431-811658 17340T 1 17339 1 17339 1
350 Mag Ski 350/ V-8 1991 - 1997 0D505450 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L 350/ V-8 1988 - 1991 0B773305 - 0D617327 23- 85674 431- 5943 8M0160608 99948 99948
5.7L (Alpha) 350/ V-8 1992 - 1996 0D617328 - 0K001526 23- 85674 431- 5943 8M0160608 99948 99948
5.7L (Alpha) 350/ V-8 1997 0K001527 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L (Bravo) 350/ V-8 1992 - 1995 0D617328 - 0F600999 23- 85674 431-811658 17340T 17339 1 17339 1
5.7L (Bravo) 350/ V-8 1996 0F601000 - 0K001526 23- 85674 431- 5943 8M0160608 99948 99948
5.7L (Bravo) 350/ V-8 1997 0K001527 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L (Gen +) 350/ V-8 1998 - 2019 0L010037 and up 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L EFI 350/ V-8 1995 0F225560 - 0F752399 23- 85674 431-811658 17340T 17339 17339
5.7L EFI 350/ V-8 1996 0F752400 - 0K001505 23- 85674 431- 5943 8M0160608 99948 99948
5.7L EFI 350/ V-8 1997 0K001506 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L EFI (Gen +) 350/ V-8 1998 - 2001 0L010035 - 0M299999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L EFI MIE (Gen +) 350/ V-8 1997 0K040300 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L MIE (LH) 350/ V-8 1988 - 1995 0B788152 - 0F622099 23- 85674 431- 5943 8M0160608 99948 99948
5.7L MIE (LH) 350/ V-8 1995 0F622151 - 0F746099 23- 85674 431- 5943 8M0160608 99948 99948
5.7L MIE (LH) 350/ V-8 1996 0F622100 - 0F622150 23- 85674 431-811658 17340T 1 17339 1 17339 1
5.7L MIE (LH) 350/ V-8 1996 - 1997 0F746100 - 0K999999 23- 85674 431-811658 17340T 1 17339 1 17339 1
Quicksilver Product Guide 903
