Page 920 - Quicksilver Product Guide (2020) - 8M0163242

INTERNAL ENGINE

Model CID/ # Cyl Year Range Serial # Range Rocker Arm Rocker Arm Rocker Arm Thread-in Press-in Press-in Rocker Arm
Kit Ball Bolt Rocker Arm Rocker Arm Rocker Arm Stud Nut
Stud Stud - .003 Stud - .013 (.33
(.076 mm) O/S mm) O/S
5.7L MPI Ski 350/ V-8 2008 - 2019 1A090000 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
5.7L Ski 350/ V-8 1985 - 1997 0A338553 - 0K999999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
5.7L Ski (Gen+) 350/ V-8 1998 - 2019 0L002005 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
5.7LX 350/ V-8 1996 - 1997 0F601000 - 0K999999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
5.7LX Bravo EFI (Gen+) 350/ V-8 1996 - 1997 0F800300 - 0K999999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
5.7LX EFI 350/ V-8 1996 - 1997 0F752400 - 0K999999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
Black Scorpion Ski (Gen+) 350/ V-8 1996 - 2007 0F800000 - 0W698432 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
Scorpion 350 350/ V-8 2008 - 2019 0W698433 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516

377 Mag 377/ V-8 2008 - 2019 1A300000 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
377 Scorpion MCM 377/ V-8 1999 - 2005 0L416146 - 0M907201 - N/A N/A - N/A N/A -
377 Scorpion Ski (Gen+) 377/ V-8 1997 - 1998 0K000656 - 0L600314 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
.2L MPI (Mercury) 377/ V-8 2015 - 2019 2A456613 and up 8M0095926 N/A 10-8M2024045 N/A N/A N/A N/A
MX 6.2L MPI 377/ V-8 2000 - 2007 0L680003 - 1A299999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
MX 6.2L MPI Horizon 377/ V-8 2002 - 2007 0M300000 - 1A299999 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
MX 6.2L MPI Horizon MIE 377/ V-8 2002 - 2019 0M300000 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
MX 6.2L MPI MIE 377/ V-8 2002 - 2019 0M300000 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
MX 6.2L MPI Ski 377/ V-8 2002 - 2019 0M317000 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516 MERCURY® MERCRUISER®
MX 6.2L Blk Scorpion Ski 377/ V-8 2001 - 2007 0L670015 - 0W698432 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
Scorpion 377 377/ V-8 2008 - 2019 0W698433 and up 35329 35331 N/A N/A 16- 34522 N.L.A. 11- 34516
Scorpion 377 HO EC 377/ V-8 2009 - 2019 1A091488 - 1A092170 8M2013606 N/A N/A 16-8M2016987 N/A N/A 11-8M2013601

233 351/ V-8 1975 - 1977 4173000 - 4902304 N.L.A. N.L.A. N/A N/A N.L.A. N.L.A. N.L.A.
255 (Ford) 351/ V-8 1973 - 1974 3258728 - 4175499 N.L.A. N.L.A. N/A N/A N.L.A. N.L.A. N.L.A.

325 427/ V-8 1969 - 1972 2278747 - 3780449 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
330 454/ V-8 1977 - 1987 4623115 - 0B816540 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
330 MIE 454/ V-8 1977 - 1980 4623115 - 5889913 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
340 MIE w/B-W 454/ V-8 1981 - 1987 5889914 - 0B788365 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
350 MIE 454/ V-8 1974 - 1976 3780450 - 4623109 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
370 TRS 454/ V-8 1978 - 1983 4179554 - 5670298 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
370 TRS 454/ V-8 1983 - 1987 5670299 - 0B714586 N.L.A. N/A N/A - N/A N/A -
400 TRS 454/ V-8 1980 - 1983 4179554 - 5670298 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
400 TRS 454/ V-8 1983 - 1986 5670299 - 0B457644 N.L.A. N/A N/A - N/A N/A -
420 454/ V-8 1987 - 1989 0A398941 - 0B622418 N.L.A. N/A N/A - N/A N/A -
425 454/ V-8 1990 - 1992 0B622419 - 0D725499 N.L.A. N/A N/A - N/A N/A -
425 (Gen V) 454/ V-8 1992 - 1993 0D725500 - 0D937011 N.L.A. N/A N/A - N/A N/A -
440 TRS 454/ V-8 1983 4179554 - 5670298 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
440 TRS 454/ V-8 1984 - 1986 5670299 - 0B485220 N.L.A. N/A N/A - N/A N/A -
450 (Gen V) 454/ V-8 1995 - 1996 0F347100 - 0F347277 N.L.A. N/A N/A - N/A N/A -
454 Mag Alpha 454/ V-8 1986 - 1988 0A631894 - 0B785148 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
454 Mag Bravo 454/ V-8 1988 - 1992 0B721206 - 0D805068 N.L.A.(1) 58041 N/A N/A N.L.A. N/A N.L.A.
454 Mag Bravo (Gen V) 454/ V-8 1992 - 1996 0D805069 - 0F801699 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag Bravo (Gen VI) 454/ V-8 1996 - 1997 0F801700 - 0K999999 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag EFI (Gen V) 454/ V-8 1994 - 1996 0F115700 - 0F802349 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag EFI Ski (Gen V) 454/ V-8 1995 - 1996 0F215800 - 0F820099 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag MPI (Gen VI) 454/ V-8 1996 - 2001 0F802350 - 0M024999 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag MPI Horizon MIE 454/ V-8 1998 - 2001 0L002200 - 0L674000 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
454 Mag MPI Ski (Gen VI) 454/ V-8 1996 - 1997 0F820100 - 0K999999 811591T N.L.A. 10-811593 N.L.A.(2) N/A N/A N/A
525 SC 454/ V-8 1991 - 1992 0D456000 - 0D725808 N.L.A. N/A N/A - N/A N/A -
525 SC (Gen V) 454/ V-8 1992 - 1996 0D763746 - 0F348963 N.L.A. N/A N/A - N/A N/A -
525 SC (Gen V) 454/ V-8 1996 0F615814 - 0F745215 - N/A N/A - N/A N/A -

Quicksilver Product Guide 911
