MERCURY RACING PROPELLER TYPE

MERCURY RACING PROPELLER TYPE

SPITFIRE XP CLEAVER 40 - 60 HP

• The Pro Finished Spitfire XP is designed for shallow running flats •The TE Cleaver is satin finish with through hub exhaust
boats. •13 tooth broached spline
• The fourth blade and flared exhaust barrel allow for lighting fast hole •Utilizes standard thrust washer and prop nut kit 11‑31990Q02
shot in shallow condition. •Applicable for Inflatable tunnels, EP Vee bottoms, Alaskan Flats and
Sport C tunnels
• Dial in RPM with available half inch pitch offerings.
• 60R to 115 HP outboards CLEAVER PROPELLER 40-60 HP

• The hub kit is not included; use 835257K6 or 835258K 2
SPITFIRE XP PROPELLER

48-891510A01
12 X 22 Pitch RH
CHOPPER II - MERCURY 30 (U.S. ORIGIN) AND 40 -
48-8M0167641 60 HP
14 x 12 Pitch RH
48-8M0167642 •The Chopper II is satin finish with over‑the‑hub exhaust
14 x 12.5 Pitch RH •13 spline rubber hub (43676T)‑ uses thrust hub 73345A1
48-8M0167643 •Applicable for light weight perfmance boats up to 60 hp
14 x 13 Pitch RH
48-8M0167659 CHOPPER II PROPELLER
13.5 x 13.5 Pitch RH
48-8M0167660
13.5 x 14 Pitch RH
48-8M0167661
13.5 x 14.5 Pitch RH
48-8M0167662
13.5 x 15 Pitch RH
48-8M0167664
13 x 15.5 Pitch RH
48-8M0167665
13 x 16 Pitch RH 48- 43592A71
48-8M0167666 10.375 Diameter x 18 Pitch RH
13 x 16.5 Pitch RH 40‑60 HP
48-8M0167667
13 x 17 Pitch RH
48-8M0167697
12.7 x 17.5 Pitch RH
48-8M0167698
12.7 x 18 Pitch RH
48-8M0167699
12.7 x 18.5 Pitch RH
48-8M0167700
12.7 x 19 Pitch RH
48-8M0167702
12.7 x 19.5 Pitch RH
48-8M0167703
12.7 x 20 Pitch RH
48-8M0167704
12.7 x 20.5 Pitch RH
48-8M0167705
12.7 x 21 Pitch RH

2021 Mercury Propeller Guide 65
