Page 85 - QUICKSILVER MARINE PARTS GUIDE (2019)

STARTERS

STARTER STARTER

50-8M6007310
For Gehl, KHD, Vermeer, Others: planetary gear reduction; 12‑Volt; CW; 11‑Tooth;
50-8M6007308
For Deutz, KHD: direct drive; 12‑Volt; CW; 11‑Tooth. Used on Deutz marine, Vermeer Trenchers and other applications with KHD
engines.
Used on Deutz and KHD industrial and marine applications. Bosch P/N: 0-001-218-172, 0-001-218-772,
Bosch P/N: 0-001-362-700 0-001-223-002
Deutz P/N: 1177441, 1178670 Deutz P/N: 0118-0180, 1180995
J & N P/N: 410-24262 J & N P/N: 410-24013, 410-24213
KHD P/N: 117-7441, 117-8670 KHD P/N: 118-0180, 118-0995
Lester P/N: 17318 Lester P/N: 18230
Letrika P/N: IS 0565 Letrika P/N: IS 1072
STARTER Liebherr P/N: 5990594, 6905510, 6905777
Volvo Penta North America, Inc. P/N:9002904386
STARTER

50-8M6007309
For Deutz engines: direct drive; 12‑Volt; CW; 9‑Tooth. 50-8M6007311
Used on Deutz, KHD, and others w/Deutz engines. For OMC: permanent magnet direct drive; 12‑Volt; CCW; 10‑Tooth.
Bosch P/N: 0-001-369-014, 0-001-369-024 Used on 115, 150, 200, 225, 275, 300HP engines Up Through 2013
Deutz P/N: 1179318 J & N P/N: 410-21054
J & N P/N: 410-24093 Lester P/N: 5723
KHD P/N: 117-9318, 117-9319 Outboard Marine Corp. P/N: 0391511, 0396235, 0397023, 0584799,
Lester P/N:
18026
0586289, 0586411, 0586731, 0586890,
STARTERS Letrika P/N: 11.130.567, AZJ3179, IS 0567 United Tech P/N: 0586897, 0586957
10517640, 4769040-M030SM, 5671440-
M030SM, 5769040-M030SM, SM47690,
SM56714
STARTER

50-8M6007312
For OMC: permanent magnet direct drive; 12‑Volt; CCW; 10‑Tooth.
Used on 85‑140HP engines.
J & N P/N: 410-21012
Lester P/N: 5397, 5719, 5722
Outboard Marine Corp. P/N: 385529, 386465, 389380, 389954, 391554,
585051, 585057, 585196, 586282, 586283
Prestolite P/N: 46-2119, 46-2399, MGL4109, MKW4001
United Tech P/N: 0139940-M030SM, 0228940-M030SM,
0246540-M030SM, 0246640-M030SM,
139940, 1791640-M030SM, 1791740-
M030SM
80
