P. 175
MERCURY® MERCRUISER® ELECTRICAL SYSTEM
TMAP TEMPERATURE AND MANIFOLD AIR PRESSURE DTS POWER HARNESS REPAIR KIT, 2-PIN
REPAIR KIT, 4-PIN, FEMALE
84-8M0062010
Use when the replacement of the entire harness is not necessary. Includes the 8M0050324
TMAP 4‑pin female connector and 4 crimp splices. As an alternative to replacing the complete engine harness, this service end is
Fits MCM 3.0L MPI EC engines TMAP sensor furnished with the necessary 2 bullet connectors to connect to the main engine
harness.
O2 SENSOR REPAIR KIT, 4-PIN, MALE Fits the Optimax outboard and MCM (DTS clean power harness)
PACKARD REPAIR KIT, 6-PIN, FEMALE
MERCURY® MERCRUISER® 84-8M0062011 84-8M0062015
Use when the replacement of the entire harness is not necessary. Includes the O2
sensor 4‑pin male connector and 4 crimp splices.
Packard 6‑pin female connector and 6 crimp splices.
Fits MCM EC engines O2 sensor
Fits MCM 3.0L MPI engines with Packard 6‑pin connector for engine O2 sensor
mini fuses
CPS CRANK POSITION SENSOR REPAIR KIT, 3-PIN, Use when the replacement of the entire harness is not necessary. Includes the
FEMALE PACKARD REPAIR KIT, 8-PIN, FEMALE
84-8M0062016
84-8M0062012 Use when the replacement of the entire harness is not necessary. Includes the
Use when the replacement of the entire harness is not necessary. Includes the Packard 8‑pin female connector and 8 crimp splices.
Crank Position 3‑pin female connector and 3 crimp splices. Fits MCM engines with Packard 8‑pin connector for engine mini fuses
Fits MCM V‑6 engines with CPS PACKARD REPAIR KIT, 2-PIN, FEMALE
MAT MANIFOLD AIR TEMPERATURE REPAIR KIT, 2-PIN,
FEMALE
84-8M0062017
Use when the replacement of the entire harness is not necessary. Includes the
84-8M0062013 Packard 2‑pin female connector and 2 crimp splices.
Use when the replacement of the entire harness is not necessary. Includes the Fits MCM engines with Packard 2‑pin connector for fuel pump, 2 amp OBDM fuse
MAT 2‑pin female connector and 2 crimp splices. and shift switch
Fits MCM 8.2L engines MAT sensor
166 Telephone Order and Assistance, (905) 636-4749; Fax (800) 217-6517
