Page 184 - Canada Parts Guide (2021) - 8M0174475
P. 184
MERCURY® MERCRUISER® FUEL SYSTEM
Model CID/ # Year Range Serial # Range Original Carb P/N Original Mfg. P/N Carb Repair Kit Needle & Seat Accel Pump Replacement Carb
Cyl. Code / Model
7.4L Bravo I/II 454/ V-8 1992 - 1994 0D603118 - 0F351999 3310-806969A 2 9780 WEBER 8M0120193 811534 NLA NLA
7.4L Bravo I/II 454/ V-8 1995 - 1997 0F352000 - 0K999999 3310-806969A 1 9780 WEBER 8M0120193 811534 NLA 3310-8M0047212
7.4L/Bravo III 454/ V-8 1993 - 1996 0D838819 - 0F800699 3310-806755A 2 9779 WEBER 8M0120193 811534 NLA NLA
7.4L/Bravo III 454/ V-8 1996 - 1997 0F800700 - 0K999999 3310-806969A 1 9780 WEBER 8M0120193 811534 NLA 3310-8M0047212
7.4L MIE 454/ V-8 1988 - 1992 5889914 - 0D715493 1347- 8288A 1 17080560 R4/4MV 823426A 1 1397- 8548 NLA NLA
7.4L MIE with Hurth 454/ V-8 1992 - 1994 0D715494 - 0F349999 3310-806969A 2 9780 WEBER 8M0120193 811534 NLA NLA
7.4L MIE with B/W 454/ V-8 1992 - 1994 0D715494 - 0F349999 3310-806969A 3 9780 WEBER 8M0120193 811534 NLA NLA
7.4L MIE 454/ V-8 1995 - 1997 0F350000 - 0K999999 3310-806969A 1 9780 WEBER 8M0120193 811534 NLA 3310-8M0047212
460 482/ V-8 1983 - 1986 4179554 - 0B485220 1393- 8862A 1 H4 13220 N.S.S. N.S.S. NLA
465 502/ V-8 1990 - 1992 0C849992 - 0F213244 N.L.A. H4 13220 N.S.S. NLA NLA(2)
465 502/ V-8 1990 - 1992 0C849992 - 0F213244 N.L.A. H4 13220 N.S.S. NLA NLA(3)
500 502/ V-8 1994 - 1995 0F213293 - 0F615766 13549A12 H4 13220 N.S.S. NLA NLA(3)
500 502/ V-8 1996 - 1998 0F615767 - 0L001772 13549A15 H4 13220 N.S.S. NLA NLA(3)
500 (Gen +) 502/ V-8 1999 0L414639 - 0L601036 13549T21 H4 13220 N.S.S. NLA NLA(3)
502 Mag 502/ V-8 1990 - 1992 0C878221 - 0D824588 1347-814623A 2 17089112 R4/4MV 823426A 1 1397- 8548 NLA NLA
502 Mag 502/ V-8 1992 - 1993 0D824589 - 0F114528 3310-806971A 1 9782 WEBER 8M0120193 811534 NLA NLA
575 502/ V-8 1986 - 1992 0A677429 - 0D763716 12377A 2 H4 NLA N.S.S. N.S.S. NLA
600 SC 502/ V-8 1991 - 2000 0D456489 - 0L601186 3312-821030A15 H4 NLA N.S.S. N.S.S. NLA(7)
600 SC 502/ V-8 1991 - 2000 0D456489 - 0L601186 3312-821030A16 H4 NLA N.S.S. N.S.S. NLA(5) MERCURY® MERCRUISER®
8.2L MIE 502/ V-8 1990 - 1992 0C878221 - 0D857199 1347-814623A 2 17089112 R4/4MV 823426A 1 1397- 8548 NLA NLA
8.2L MIE 502/ V-8 1990 - 1992 0C878221 - 0D857199 3310-817693A 1 9774 WEBER 8M0120193 811534 NLA NLA
8.2L MIE 502/ V-8 1993 - 1996 0D857200 - 0F819619 3310-806971A 1 9782 WEBER 8M0120193 811534 NLA NLA
500 Bulldog 540/ V-8 1990 - 1995 0C577254 - 0F348987 13549A10 H4 13220 N.S.S. NLA NLA(3)
500 Bulldog 540/ V-8 1995 - 2001 0F615762 - 0M050281 13549A23 H4 13220 N.S.S. NLA NLA(3)
800 SC 572/ V-8 1993 - 1996 0D763836 and up 3312-821030A17 H4 NLA N.S.S. N.S.S. NLA(7)
800 SC 572/ V-8 1993 - 1996 0D763836 and up 3312-821030A18 H4 NLA N.S.S. N.S.S. NLA(5)
(1) Automatic choke
(2) Black
(3) Blue
(4) Electric choke
(5) Front (Blue)
(6) In-Line
(7) Rear (Blue)
(8) Spacer mounted
(9) Use if original carb is MerCarb
(10) Use if original carb is Rochester
(11) Use w/ in-line transmission
(12) Use w/ V-drive transmission
(13) V-drive
(14) Wedge mounted
(17) TKS Retrofit Kit
2021 Mercury Precision Parts Guide 175
