Waterbird Classic Mini Sprinkler
®

Application

• Orchards
• Nurseries
• Overhead frost protector
• Vineyards
Engineered to provide improved water
application for low volume, under-tree and
under vine installations.

Features
• Aerofoil shaped frame improves distribution
• Snap Fit bearing provides easy field
disassembly
• Anti-insect/dust proof spinner retracts to
protect nozzle when not in operation
• Improved distribution characteristics with
large droplet size being less susceptible to
wind effects
• Low angle of throw for maximising under
foliage penetration Deflector Plate LTD Throw Deflector Tab
SPP2600DP SPP412L SPP413L
• Available with snap-off deflector for
irrigating young trees. (Reduces diameter to
30% of stated performance) Performance Chart
• Also available with Limited Throw Deflector Jet Colour Pressure Diam. Diam. Diam Diam Flow Stream
(LTD) Orifice (kPa) Std with Ltd Deflector Deflector (L/h) Height*
Diam. Spinner Spinner TAB Spinner Plate (m)
• Retrofittable deflector plate creates fixed (m) (m) (m) (m)
spray pattern for reduced throw on young 100 4.9 30 0.56
Black
plants 1.00 mm
• Available (for easy identification) in eight 150 5.5 4.0 1.0 1.4 36 0.62
colour coded flow rates ranging from 29 Lph 200 5.8 41 0.65
to 304 Lph White 100 6.1 44 0.56
• Recommended operating pressure as 1.05 mm 150 6.9 4.6 1.4 1.4 55 0.62
shaded on chart for optimum performance 200 7.3 64 0.65
• Maximum diameter of throw in excess of 10 Maroon 100 6.8 62 0.57
metres 1.25 mm
150 7.8 5.1 1.5 1.4 76 0.71
200 8.3 89 0.90
Specifications
Green 100 7.3 81 0.60
• Inlet: 10 mm MBSP/NPT 1.40 mm
150 9.2 5.3 1.6 1.4 99 0.83
• Recommended Pressure Range: 200 10.3 115 0.90
100 – 200 kPa
Blue 100 8.4 108 0.60
• Materials: Frame, bearing and nozzle: 1.65 mm
Acetal. Spinner: Nylon 150 9.4 6.0 1.7 1.6 134 0.80
200 10.5 156 0.92
Grey 100 8.5 125 0.60
1.80 mm
150 9.4 5.5 2.7 1.7 155 0.77
200 10.8 178 0.90
Yellow 100 8.3 156 0.65
2.0 mm
150 9.4 N/R 2.5 1.8 192 0.75
200 10.3 221 0.85
Red 100 8.8 214 0.74
2.3 mm
150 10.2 N/R 2.5 1.8 265 0.97
200 10.3 304 1.05
Shaded portions indicate recommended operating pressures.
Diameters based on spinner installed 250 mm above ground.
* Measured from spinner outlet.
