Page 165 - Toro Irrigation Product Catalogue August 2020

Filters

Filtration device designed to trap Ordering Information
foreign particles in the water Code Description
and reduce clogging of emitters. 10144355 13 mm IN-LINE FILTER
10144365 16 mm IN-LINE FILTER
Application 10144375 19 mm IN-LINE FILTER
10144405 13 mm SNAP-ON FILTER
For low pressure (up to 300 kPa) micro
irrigation systems. 10144415 16 mm SNAP-ON FILTER
10144425 19 mm SNAP-ON FILTER
Features
Pressure Loss vs Flow
• In-line model with single barb inlet and 19 mm Filter
outlet
40
• Snap-On model for direct connection to
standard tap adaptors 30
• 80 mesh screen filter Pressure Loss (kPa) 20 • 19 mm
• Easily taken apart for cleaning 10
• Effective compact filter with minimal 0 600 1200 1800 2400 3000
flow loss Flow Rate (Lph)

Pressure Loss vs Flow
13 and 16 mm Filter

40
Pressure Loss (kPa) 20 • 13 mm
30

10

0 200 400 600 800 1000 • 16 mm
Flow Rate (Lph)

Specifications

Dimensions Materials
Assembled Base/Connection
L W Weight Tail Body Washer Screen Type
(mm) (mm) approx.
In-Line Filter
Inlet: BARB
13 mm Inlet: Filter & Nut: 13 mm/16 mm
and 132 33 28 g acetal polypropylene rubber HDPE
16 mm Outlet: BARB
13 mm/16 mm
Inlet: BARB 19 mm
Filter & Nut:
Inlet:
19 mm 175 40 43 g acetal polypropylene rubber HDPE Outlet: BARB 19 mm
Snap-On Filter
Snap-On
Inlet: acetal Inlet: SNAP-ON
13 mm CONNECTOR
and 134 33 35 g – Filter & TPV HDPE
Outlet: BARB
Sleeve
In-Line Snap-On In-Line 16 mm Snap-On: 13 mm/16 mm
Filter Filter Filter screen polypropylene
detail Snap-On
Inlet: acetal Inlet: SNAP-ON
19 mm 175 40 51 g – Filter & TPV HDPE CONNECTOR
Sleeve
Snap-On: Outlet: BARB 19 mm
polypropylene
This product has been independently
tested by the Australian Irrigation
Technology Centre, report No A98052
and A00007.

153
