Page 191 - 2020 Pricebook update

INFINITY Series Sprinklers with SMART ACCESS ™
™

Disc. Pack List Price
Code Description Code Size excl. GST*

Ordering Information - INF35 & INF55
INFX5-XXX-XX
Pressure
Body Inlet Arc Nozzle Regulation * Activation Type Optional
INFX 5 XX X X X

3 - 1“ (25mm) 5 - Full/Part Circle INF35 5 - 50 psi 1 - Standard Solenoid 7 - Effluent
5 - 1½” (40mm) 30, 31, 32, 33, 34 2 - Spike Guard Solenoid
™
35, 36, 37 6 - 65 psi
™
3 - Nickel-Plated Spike Guard Solenoid**
8 - 80 psi
INF55 4 - DC Latching Solenoid (DCLS)
51, 52, 53, 54, 55 1 - 100 psi 5 - Integrated GDC Decoder with DCLS
56, 57, 58, 59 6 - Integrated LSM with DCLS
Example: When specifying an INF35 Series Sprinkler with #34 nozzle, pressure regulation at 65 psi and DC Latching Solenoid,
you would specify INF35-346-4
* All sprinklers are equipped with the adjustable pilot valve that allows settings at 50, 65, 80 and 100 psi. Note: Not all models are available
™
** Nickel-Plated Spike Guard Solenoid not stocked in Australia
INF34 Series - (Full Circle) Sprinklers with Dual Trajectory (25° or 15°)

INF34-3XX-1 25mm ACME Inlet, Full Circle, Dual Trajectory, Standard Solenoid GH 4 550.15
INF34-3XX-2 25mm ACME Inlet, Full Circle, Dual Trajectory, Spike Guard Solenoid GH 4 599.38
™
INF34-3XX-3 25mm ACME Inlet, Full Circle, Dual Trajectory, Nickel-Plated Spike Guard Solenoid GH 4 611.69
™
INF34-3XX-4 25mm ACME Inlet, Full Circle, Dual Trajectory, DC Latching Solenoid GH 4 588.31
INF34-3XX-5 25mm ACME Inlet, Full Circle, Dual Trajectory, GDC Module w/ DC Latching Solenoid GH 4 845.54
INF34-3XX-6 25mm ACME Inlet, Full Circle, Dual Trajectory, LSM w/ DC Latching Solenoid GH 4 891.55

INF54 Series - (Full Circle) Sprinklers with Dual Trajectory (25° or 15°)

INF54-5XX-1 40mm ACME Inlet, Full Circle, Dual Trajectory, Standard Solenoid GH 4 611.69
INF54-5XX-2 40mm ACME Inlet, Full Circle, Dual Trajectory, Spike Guard Solenoid GH 4 649.85
™
INF54-5XX-3 40mm ACME Inlet, Full Circle, Dual Trajectory, Nickel-Plated Spike Guard Solenoid GH 4 667.08
™
INF54-5XX-4 40mm ACME Inlet, Full Circle, Dual Trajectory, DC Latching Solenoid GH 4 636.31
INF54-5XX-5 40mm ACME Inlet, Full Circle, Dual Trajectory, GDC Module w/ DC Latching Solenoid GH 4 893.54
INF54-5XX-6 40mm ACME Inlet, Full Circle, Dual Trajectory, LSM w/ DC Latching Solenoid GH 4 939.55
GOLF Ordering Information - INF34 & INF54

INFX4-XXX-XX
Pressure
Body Inlet Arc Nozzle Regulation * Activation Type Optional
INFX 4 XX X X X
3 - 1” (25mm) 4 - Full Circle INF34 5 - 50 psi 1 - Standard Solenoid 7 - Effluent
5 - 1½ (40mm) 31, 32, 33, 34, 35 2 - Spike Guard Solenoid
™
36, 37 6 - 65 psi 3 - Nickel-Plated Spike Guard Solenoid**
™
8 - 80 psi
INF55 4 - DC Latching Solenoid (DCLS)
51, 52, 53, 54, 55 1 - 100 psi 5 - Integrated GDC Decoder with DCLS
56, 57, 58, 59 6 - Integrated LSM with DCLS
Example: When specifying an INF34 Series Sprinkler with #34 nozzle, pressure regulation at 80 psi and Standard Solenoid,
you would specify INF34-348-1

* All sprinklers are equipped with the adjustable pilot valve that allows settings at 50, 65, 80 and 100 psi. Note: Not all models are available
** Nickel-Plated Spike Guard Solenoid not stocked in Australia
™
Page 172 * All prices exclude a 10% GST
