20 STEEL SYSTEMS THERMALLY INSULATED DOORS & WINDOWS

Janisol HI

For powerful insulation

Highly insulated steel doors reduce thermal transmittance
to a minimum

In busy public buildings in particular, With a basic depth of 80 mm, inll unit
the requirements for security, durability thicknesses of up to 56 mm can be used.
and thermal insulation have increased A comprehensive and coordinated range
dramatically. Janisol HI steel doors of ttings and accessories, as well as a
conveniently combine mechanical range of thresholds, which can be
stability with high thermal insulation selected to suit the situation, provide
properties in one single steel prole the perfect solution for all possible
system. applications. Thanks to the specially
Thanks to insulating bars made from formed insulating bars, the lock can
glass bre-reinforced polyurethane, be installed in the centre of the prole
Janisol HI achieves U values to very easily and efciently.
d
1.0 W/m K.
2

Steel windows with optimum thermal break

Modern windows must meet a number glazing and 0.8 W/m K for windows.
2
of different demands and perform a With a basic depth of 90 mm, vent
variety of functions. They must save heights of up to 2800 mm and a vent
energy, be airtight, watertight and weight of 180 kg are possible. What is
easy to use, meet structural require- more, different inll unit thicknesses
ments, but also be highly attractive. of up to 66 mm can be used. Due to
Janisol HI steel windows and xed the slimline external face width and the
glazing feature insulating bars made wide variety of coating options, Janisol
from glass bre-reinforced polyure- HI steel windows can meet high thermal
thane and boast optimum thermal insulation requirements in terms of both
and structural properties. They achieve function and design.
U values to 0.69 W/m K for xed
2
w
