Page 575 - MODUL SPEKTRUM FIZIK SPM

✔1 : Labels on both axes correct
✔2 : Units on both axes correct
✔3 : Uniform scale on both axes
✔4 : 3-4 points plotted correctly
✔5 : All 5 points plotted correctly
✔6 : Best fit line is drawn
✔7 : Size of graph at least 5 x 4 (10 cm x 8 cm)
(Counted from origin until the furthest point)

5 marks - 7✔
4 marks - 5✔ - 6✔
3 marks - 3✔ - 4✔
2 marks - 2✔
1 mark - 1✔

(e) Relationship between Dq and t
Dq is directly proportional to t
1
(Accept “increases linearly” based on student’s
graph)

(SET 7)

Question Answer Scheme Marks Allocated
(a)(i) MV: Object distance// u 1
(a)(ii) RV: Image distance// v 1
(a)(iii) CV: Power of convex lens 1
(b)(i) Readings of v
Diagram 1.2: 13.3 cm
Diagram 1.3: 8.6 cm
Diagram 1.4: 7.1 cm
Diagram 1.5: 6.7 cm
Diagram 1.6: 6.4 cm 2
Diagram 1.7: 6.1 cm

✔1 : 4 readings correct
✔2 : All readings correct

(b)(ii) Tabulation for u, v, and

u (cm) v (cm) $ (cm ) $ (cm )
-1
-1
% &
8.0 13.3 0.125 0.075
12.0 8.6 0.083 0.116
16.0 7.1 0.063 0.141
20.0 6.7 0.050 0.149 5
24.0 6.4 0.042 0.156
28.0 6.1 0.036 0.164

✔1 : All headings for u, v, and correct

✔2 : All units for u, v, and correct
