Fig. 2 – A 100°countersink head is commonly used in Fig. 3 – Efficient drilling inclined surfaces is not a problem for
manufacturing aircraft parts. flat bottom heads.
The same angle is often needed for riveting. The MULTI-MASTER
provides an appropriate solution with its newly developed 2-flute
countersink heads (Fig. 2) with 100°-point angle in diameters
9.525-19.05 mm (.375”-.750”). The heads are also suitable for
chamfering and spot drilling.
The growth of 5-axis CNC machines has brought new efficient
strategies for milling complex 3D shapes. This has increased the
demands for cutting tools with a specific geometry, i.e., barrel
endmills. Following new needs, MULTI-MASTER replenished its
range with appropriate heads that were successfully adopted by
the customer, particularly in the aerospace, medical, and die and
mold industries.
In hole making, the recently introduced precise flat bottom
drilling heads have considerably expanded the line applicability
in shallow drilling operations for steel, stainless steel, and cast
iron (ISO P and K groups of application) including direct drilling
inclined surfaces (Fig. 3). The head diameter tolerance meets the Fig. 4 – A disc-type blank head is ideal for customized
accuracy grade h7, while the head drilling capabilities extend up solutions in milling slots and grooves. The hexalobular
to 1.2 of the diameters. recess in a head face is intended for applying TORX-tipped
ISCAR’s motto “be more user- friendly” relates to the recent wrenches with controlled torque for reliable clamping.
upgrade of the MULTI-MASTER groove milling head with a new directions of one of the leading rotating tool systems with
clamping option. Incorporating a hexalobular TORX recess into exchangeable carbide heads, but distinctly show that the sources
a head design enables securing the head with ISCAR’s fix- or for development and improvement of system capabilities are far
adjustable torque wrenches for reliable clamping. from being exhausted. The needs of modern manufacturing bring
An advantage of the MULTI-MASTER is that the heads are more and more requests and open new application fields that
excellent to produce special profiles. This line contains several require an appropriate tooling response. The history of ISCAR’s
threaded blanks from uncoated cemented carbides for tailor- MULTI-MASTER concludes with high versatility of tools with
made products. A short time ago the range of available blanks exchangeable heads and highlights their ability to meet growing
was expanded by disc-shape semi-finished heads (Fig. 4), which industrial demands.
are successfully used for customized solutions in milling slots,
grooves, threads, splines, and many more. For more information,
The above examples not only illustrate the development Website: www.iscar.in
