processes, production processes can be displayed digitally and accuracy to achieve excellent surfaces and the highest form
transparently. and position tolerances. This improvement is achieved via a
groundbreaking calibration concept, an innovative cooling
GROB Universal Machines concept for all relevant components and high dynamic axis
About fifteen years after the first G350, with its horizontal configuration stability. No compromises were made to the
spindle arrangement, was unveiled at the EMO 2007, the 5-axis combination of outstanding ergonomics and perfect automation
technology of universal machining centers has established capacity for this. The G150 is optimally positioned for the
itself in the mechanical engineering sector and gained a firm precision engineering, medical technology, tool and mould
foothold in the market. A successful development which is manufacture, mechanical engineering and aerospace industries.
ultimately attributable to the high dynamic performance and The machine’s warm-up cycle is now individually adapted to
great innovation of the G-module concept and which has the actual situation. The machine detects when production can
made the GROB universal machining centers, which are now be started and when to end the warm-up cycle autonomously
in their second generation, such a great success. Equipped based on the geometry parameters.
with the latest developments, the second generation of this If recalibration is required, the calibration software detects
tried and tested machine concept will be run through its paces. this and notifies the operator accordingly. In combination
The 5-axis universal machining centers are flexibly adaptable with a pallet storage system, calibration can even be initiated
and extendable for every application, whether it is as a milling completely automatically. Process reliability is integral at GROB,
and turning option, as a rotary pallet storage system, or with and not left to chance. An important foundation for the success
or without a pallet changer, automation or trend-setting of the G-series is the unique combination of ergonomics suited
GROB4Pilot operator panel. to a workshop and perfect automation capabilities.
The possible uses of the machine concept are extended yet The machine is suitable for both a job shop environment as
further with the G550 – Generation 2. Its hallmarks are the high well as for series production. In combination with a pallet storage
dynamic performance and stability of the machining centers, as system, the machine can be used for prototypes in the early shift
well as the much narrower design and the marked reduction in and then for series production at night, for example.
chip-to-chip time. The maximum tool length has been increased
as well as number of HSK-A63 tools within the machine. Like GROB Automation solutions
its little sister, one of the impressive features of the G550 – Thanks to intensive development work, GROB is now able to
Generation 2 is its ergonomically favorable tool-loading point offer all its automation solutions such as the pallet changing
at the operator’s end. The second generation of the G550 is system, the pallet storage system (PSS-R) and, since this year,
also characterized by its optimum chip fall behavior. It prevents the linear pallet storage system (PSS-L) from its own production.
the build-up of heat in the machine as a result of chips being GROB’s automation technology enables flexible adaptation to
left on the workpiece or on the clamping mechanism. Cleaning capacities and guarantees perfectly coordinated pallet handling.
components before changing the workpiece is also easy and In the process, GROB offers self-made components for its entire
the ‘emptying’ option ensures that almost no cooling lubricant product range, from semi-automatic to fully automatic production
residue is left on the workpiece. with the highest quality standards. The automation solutions
The G350T, G550T and G750T 5-axis universal machining ensure an efficient production process and guarantee optimal
centers provide customers in the machining industry almost work piece handling. All fully automatic technologies come from
limitless options for milling and turning workpieces from various our own production and can be optimally adapted to the specific
materials. Three linear and two rotary axes enable five-sided needs of the customers.
machining with 5-axis simultaneous interpolation.

The New G150 Dominant in the Automotive Industry
With the newly developed G150, GROB rounds off the bottom
end of its universal machining center range. The G150 profits
from market dominance in the automotive industry due to the
modular G-series system, which has continuously defined the
bar for productivity and process safety.
For complex components with highest standards,
development of the G150 placed particular emphasis on spatial
