6-BTM™ BOOST TIMING MASTER
• Multiple spark, capacitive discharge ignition control
• Supplied w/ 3,000, 6,000, 7,000 & 8,000 RPM Module
• Supplied with rubber shock mounts
DIGITAL 6A IGNITION CONTROL • 110 millijoules per spark up to 15,000 RPM
The Digital 6A is a microprocessor controlled, capacitive discharge ignition that multi
sparks up to 3,000 RPM providing easy starts, a clean, smooth idle and quick throttle PART NO. DESCRIPTION
response by optimizing your engines efficiency.
6462 6-BTM Boost Timing Master - For 4, 6, or 8-cylinders
PART NO. DESCRIPTION

6201 Digital 6A Ignition Control WIRING HARNESSES
62013 Digital 6A Ignition Control - Black Harnesses plug directly into your factory coil and
6425 Digital 6AL Ignition Control w/ Rev Control harness, then four color coded wires plug into the
64253 Digital 6AL Ignition Control w/ Rev Control - Black corresponding wires of the MSD.
6421 6AL-2 Ignition Control w/ Rotary Dials
64213 6AL-2 Ignition Control w/ Rotary Dials - Black PART NO. DESCRIPTION
6530 Digital Programmable 6AL-2
65303 Digital Programmable 6AL-2 - Black 8874 MSD to Ford TFI Harness
8876 MSD to GM Dual Connector Coil
8877 MSD to GM ‘96-On Single Connector Coil

DIGITAL-6 PLUS™ EXTREME DUTY
• Built-in Drag Race features 6ALN™ IGNITION CONTROL
• 2-Step rev control
• Single stage retard Extreme duty 6ALN can handle the harshest racing
• Start retard environments, includes a built-in rev limiter.
PART NO. DESCRIPTION PART NO. DESCRIPTION

6430 6ALN™ Ignition Control
6520 Digital-6 Plus™ Ignition Control

7AL-2™ PLUS PROGRAMMABLE
A staple in the drag race community, features a built-in 2 DIGITAL-7 PLUS™
step rev control and its famous high output spark energy. • Map a complete timing curve for every gear
PART NO. DESCRIPTION • Select the rpm limiter value in rpm/seconds
• There is a cam sync output for fuel controllers
7222 7AL-2 Plus Ignition Control or data acquisition
72223 7AL-2 Plus Ignition Control - Black PART NO. DESCRIPTION
7531 Programmable Digital-7 Plus Ignition Control
7AL-3™
For racers that want adjustments at their fingertips, the
7AL-3 is the right choice. The 7AL-3 packs high voltage
with four step retards, three rev limits, and an rpm switch. PROGRAMMABLE 7-PLUS
PART NO. DESCRIPTION ACCESSORIES
PART NO. DESCRIPTION
7330 7AL-3 Ignition Control
7551 Manual Launch Control
7542 Adjustable Intensity LED Shift Light
8-PLUS™ 7555 Inductive Pickup
If you’re running alcohol and high compression and/or a
turbo/blower this one can ignite it all.
PART NO. DESCRIPTION POWER GRID™
IGNITION SYSTEM
7805 8-Plus Ignition Control • USB connection for ease of programming
• Timing based on engine rpm, gear value
CAN-BUS EXTENSION and time
HARNESSES • Five retard stages for nitrous
• Output switch set on rpm on time
PART NO. DESCRIPTION
PART NO. DESCRIPTION
7784 4 Feet 7730
7786 6 Feet Power Grid Ignition System™ - Controller
7789 Harness Adapter - #7730 to Digital-7 Programmable 7720 Power Grid Ignition System™ - Ignition
