SELECTION GUIDE SOLID CARBIDE V7 MILL INOX END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
INCH
EMC75 ◎ ○ ○ ◎ ◎ ○
EMD60 CARBIDE, 4 FLUTE STUB LENGTH ◆ D1/8 D1 1020
EMC76
EMD61 CARBIDE, 4 FLUTE STUB LENGTH CORNER RADIUS ◆ D1/8 D1 1021 ◎ ○ ○ ◎ ◎ ○
EMB12
EMB37 CARBIDE, 4 FLUTE REGULAR LENGTH ◆ D1/8 D1 1022 ◎ ○ ○ ◎ ◎ ○
EMB13
EMB38 CARBIDE, 4 FLUTE REGULAR LENGTH CORNER RADIUS ◆ D1/8 D1 1023 ◎ ○ ○ ◎ ◎ ○

EMB20 CARBIDE, 4 FLUTE EXTENDED LENGTH LONG REACH ◆ D1/4 D1 1024 ◎ ○ ○ ◎ ◎ ○

EMB78
EMB79 CARBIDE, 4 FLUTE REGULAR LENGTH BALL NOSE ◆ R1/16 R1/2 1025 ◎ ○ ○ ◎ ◎ ○
EMB76
EMB77 CARBIDE, 5 FLUTE REGULAR LENGTH ◆ D1/4 D1 1026 ◎ ○ ○ ◎ ◎ ○
◆ U.S.A Stock
METRIC
EMB41
EMB42 CARBIDE, 4 FLUTE SHORT LENGTH ◇ D3.0 D20.0 1027 ◎ ○ ○ ◎ ◎ ○
EMB43
EMB44 CARBIDE, 4 FLUTE SHORT LENGTH CORNER RADIUS ◇ D3.0 D20.0 1028 ◎ ○ ○ ◎ ◎ ○
EMB14
EMB39 CARBIDE, 4 FLUTE REGULAR LENGTH ◇ D3.0 D25.0 1029 ◎ ○ ○ ◎ ◎ ○
EMB15
EMB40 CARBIDE, 4 FLUTE REGULAR LENGTH CORNER RADIUS ◇ D3.0 D25.0 1030 ◎ ○ ○ ◎ ◎ ○
EMB74
EMB75 CARBIDE, 4 FLUTE REGULAR LENGTH BALL NOSE ◇ R1.5 R12.5 1031 ◎ ○ ○ ◎ ◎ ○
EMB72
EMB73 CARBIDE, 5 FLUTE REGULAR LENGTH ◇ D6.0 D25.0 1032 ◎ ○ ○ ◎ ◎ ○

RECOMMENDED CUTTING CONDITIONS 1033
◇ Call for Availability
