SELECTION GUIDE STANDARD COBALT & HSS END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
INCH
E2030
E1030 HSSCo8 & HSS, 2 FLUTE REGULAR LENGTH D1/8 D2 1219 ◎ ◎ ○ ○ ○
E2080
E1080 HSSCo8 & HSS, 2 FLUTE LONG LENGTH D1/4 D2 1221 ◎ ◎ ○ ○ ○
E2033
E1033 HSSCo8 & HSS, 2 FLUTE EXTENDED LENGTH D1/8 D1-1/4 1222 ◎ ◎ ○ ○ ○
E2050
E1050 HSSCo8 & HSS, 2 FLUTE REGULAR LENGTH DOUBLE D1/8 D1 1223 ◎ ◎ ○ ○ ○
E2110
E1110 HSSCo8 & HSS, 2 FLUTE REGULAR LENGTH BALL NOSE R1/16 R1 1225 ◎ ◎ ○ ○ ○
E2111
E1111 HSSCo8 & HSS, 2 FLUTE EXTENDED LENGTH BALL NOSE R1/16 R1/2 1226 ◎ ◎ ○ ○ ○
E2112
E1112 HSSCo8 & HSS, 2 FLUTE REGULAR LENGTH BALL NOSE DOUBLE R1/16 R1/2 1227 ◎ ◎ ○ ○ ○
E2031
E1031 HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH D1/8 D1 1228 ◎ ◎ ○ ○ ○
E2032
E1032 HSSCo8 & HSS, 6 FLUTE REGULAR LENGTH D5/8 D2 1230 ◎ ◎ ○ ○

E2034
E1034 HSSCo8 & HSS, 4 FLUTE LONG LENGTH D1/4 D1 1231 ◎ ◎ ○ ○ ○
E2035
E1035 HSSCo8 & HSS, 6 FLUTE LONG LENGTH D1-1/8 D2 1231 ◎ ◎ ○ ○
E2036 ◎ ◎ ○ ○ ○
E1036 HSSCo8 & HSS, 4 FLUTE EXTRA LONG LENGTH D1/4 D1 1232
E2037
E1037 HSSCo8 & HSS, 6 FLUTE EXTRA LONG LENGTH D1-1/4 D2 1232 ◎ ◎ ○ ○
E2051
E1051 HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH DOUBLE D1/8 D1 1233 ◎ ◎ ○ ○ ○
E2031 ◎ ◎ ○ ○ ○
E1031 HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH 3/4 SHANK D3/4 D1 1235
E2032
E1032 HSSCo8 & HSS, 6&8 FLUTE REGULAR LENGTH 3/4 SHANK D1-1/8 D2 1235 ◎ ◎ ○ ○

E2020 HSSCo8, 4 FLUTE REGULAR LENGTH BALL NOSE R1/16 R1 1236 ◎ ◎ ○ ○ ○

E2021 HSSCo8, 4 FLUTE LONG LENGTH BALL NOSE R1/8 R1/2 1237 ◎ ◎ ○ ○ ○

E2069 HSSCo8, 4 FLUTE REGULAR LENGTH BALL NOSE DOUBLE R1/16 R1/2 1238 ◎ ◎ ○ ○ ○

E2039
E1039 HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH CENTER CUTTING D1/8 D1-1/2 1239 ◎ ◎ ○ ○ ○
E2042
E1042 HSSCo8 & HSS, 6 FLUTE REGULAR LENGTH CENTER CUTTING D1/2 D2 1241 ◎ ◎ ○ ○
