SPIRAL SPIRAL T7236/T6236/T8236 SERIES
POINT TAPS T7B17/T6B17/T8B17 SERIES POINT TAPS T7G36/T6G36/T8G36 SERIES

STANDARD TAPS : SPIRAL POINT PLUG STYLE SPIRAL POINTED TAP, 6 EXTENSION
"
Oversize Tap

Extended length for greater reach
Thread Depth / 3.0×D Thread Depth / 3.0×D
Hole Type Hole Type
USCTI USCTI Long Shank

USCTI
M
GS HSS MF USCTI 4P~5P Bright Steam TiN +.127mm GS HSS UNC Long Shank 4P~5P Bright Steam TiN
Oxide
Oxide
UNF
302
oversize
EDP No. Thread Per Inch EDP No.
SIZE Pitch No. of Flute Steam SIZE Overall No. of Steam
Bright TiN UNC UNF Limit Length Flutes Bright TiN
Oxide Oxide
M4 0.7 2 T7B17240 T6B17240 T8B17240 #6 32 — H3 6 2 T7236243 T6236243 T8236243
M5 0.8 2 T7B17280 T6B17280 T8B17280 #8 32 — H3 6 2 T7236283 T6236283 T8236283
M6 1 2 T7B17310 T6B17310 T8B17310 #10 24 — H3 6 2 T7236323 T6236323 T8236323
M8 1.25 2 T7B17360 T6B17360 T8B17360 #10 — 32 H3 6 2 T7236343 T6236343 T8236343
M8 1 2 T7B17370 T6B17370 T8B17370 1/4 20 — H3 6 2 T7236403 T6236403 T8236403
M10 1.5 3 T7B17420 T6B17420 T8B17420 1/4 — 28 H3 6 2 T7236423 T6236423 T8236423
M10 1.25 3 T7B17430 T6B17430 T8B17430 5/16 18 — H3 6 2 T7236443 T6236443 T8236443
M12 1.75 3 T7B17500 T6B17500 T8B17500 5/16 18 — H3 6 3 T7G36443 T6G36443 T8G36443
M16 2 3 T7B17600 T6B17600 T8B17600 5/16 — 24 H3 6 2 T7236463 T6236463 T8236463
5/16 — 24 H3 6 3 T7G36463 T6G36463 T8G36463
▶Refer to technical data on page 520~554.
3/8 16 — H3 6 3 T7236483 T6236483 T8236483
3/8 — 24 H3 6 3 T7236503 T6236503 T8236503
7/16 14 — H3 6 3 T7236523 T6236523 T8236523
7/16 — 20 H3 6 3 T7236543 T6236543 T8236543
1/2 13 — H3 6 3 T7236563 T6236563 T8236563
1/2 — 20 H3 6 3 T7236583 T6236583 T8236583
5/8 11 — H3 6 3 T7236643 T6236643 T8236643
▶Refer to technical data on page 520~554.
