SELECTION GUIDE SOLID CARBIDE X5070 END MILLS

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL DESCRIPTION PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
MIN MAX ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
INCH
High Feed End Mill
G826 CARBIDE, 4FLUTE STUB LENGTH CORNER RADIUS HIGH FEED ◆ D1/8 D1/2 630 ○ ○ ◎ ◎

G8A43 CARBIDE, 2 FLUTE STUB LENGTH BALL NOSE ◆ R1/64 R1/4 631 ○ ○ ◎ ◎
with EXTENDED NECK

G850 CARBIDE, 4 FLUTE STUB LENGTH CORNER RADIUS ◆ D1/16 D3/4 632 ○ ○ ◎ ◎
with EXTENDED NECK
G851 CARBIDE, 6&8 FLUTE 45°HELIX CORNER RADIUS ◆ D1/4 D1 633 ○ ○ ◎ ◎

METRIC ◆ U.S.A Stock
High Feed End Mill
G859 CARBIDE, 4FLUTE STUB LENGTH CORNER RADIUS HIGH FEED ◇ D2.0 D16.0 634 ○ ○ ◎ ◎
High Feed End Mill
G854 CARBIDE, 4FLUTE STUB LENGTH CORNER RADIUS HIGH FEED ◇ D2.0 D16.0 635 ○ ○ ◎ ◎

G8A46 CARBIDE, 2 FLUTE BALL NOSE for RIB PROCESSING ◇ R0.05 R2.0 636 ○ ○ ◎ ◎

G8A54 CARBIDE, 2 FLUTE BALL NOSE for RIB PROCESSING ◇ R0.25 R1.0 640 ○ ○ ◎ ◎

G8A28 CARBIDE, 2 FLUTE BALL NOSE ◇ R0.05 R6.0 641 ○ ○ ◎ ◎

G8A38 CARBIDE, 2 FLUTE STUB LENGTH BALL NOSE ◇ R0.5 R12.5 642 ○ ○ ◎ ◎
with EXTENDED NECK

G8A53 CARBIDE, 2 FLUTE MINIATURE BALL NOSE ◇ R0.2 R1.0 643 ○ ○ ◎ ◎

G8A59 CARBIDE, 3 FLUTE BALL NOSE ◇ R1.5 R10.0 644 ○ ○ ◎ ◎

G8A36 CARBIDE, 2 FLUTE STUB LENGTH CORNER RADIUS ◇ D0.3 D20.0 645 ○ ○ ◎ ◎
with EXTENDED NECK
G8A50 CARBIDE, 2 FLUTE MINIATURE CORNER RADIUS ◇ D0.3 D2.0 647 ○ ○ ◎ ◎

G8A47 CARBIDE, 4 FLUTE CORNER RADIUS with EXTENDED NECK ◇ D3.0 D12.0 648 ○ ○ ◎ ◎

G8A37 CARBIDE, 4 FLUTE STUB LENGTH CORNER RADIUS ◇ D1.0 D20.0 649 ○ ○ ◎ ◎
with EXTENDED NECK

G8A39 CARBIDE, 6 FLUTE 45°HELIX CORNER RADIUS ◇ D6.0 D20.0 650 ○ ○ ◎ ◎
with EXTENDED NECK

RECOMMENDED CUTTING CONDITIONS 651
