FLANGED WASHERS

STEEL
C
PART NO. A B DIA
For open-arm clamps. Use two flanged washers to CL-832-TW #8-32 or M4 7/16 15/32
mount spindle, one above the arm and one below. CL-3166-TW #10-32 or M5 1/2 9/16
CL-147-TW 1/4-20 or M6 9/16 5/8
A DIA BOLT CL-148-TW 19/32 11/16
Two flanged washers IBP CL-51610-TW 5/16-18 or M8 3/4 7/8
required per clamp CL-3811-TW 3/8-16 or M10 15/16 1
IBP
CL-1213-TW 1/2-13 or M12 1-5/32 1-1/4
B
CL-5811-TW 5/8-11or M16 1-3/8 1-15/32
STAINLESS STEEL
C DIA CL-832-TW-S #8-32 or M4 7/16 15/32
CL-3166-TW-S #10-32 or M5 1/2 9/16
CL-147-TW-S 9/16 5/8
1/4-20 or M6
CL-148-TW-S 19/32 11/16
CL-51610-TW-S 5/16-18 or M8 3/4 7/8
CL-3811-TW-S 3/8-16 or M10 15/16 1
BOLT RETAINERS

IBP BR (FOR HTC & VTC CLAMPS)
E
SPINDLE A
A DIA PART NO. SIZE DIA B C D E
D CL-142000-BR 1/4-20 or M6 9/32 1-1/4 1/2 3/16 3/32
IBP
CL-518000-BR 5/16-18 or M8 21/64 1-1/4 5/8 1/4 3/32
CL-316000-BR 3/8-16 or M10 17/32 1-1/2 3/4 5/16 1/8
C
CL-113000-BR 1/2-13 or M12 9/16 1-5/8 7/8 3/8 1/8
BR S CL-511000-BR 5/8-11 or M16 11/16 1-7/8 1-1/4 3/8 1/8
For VTC clamps For TC clamps B
S (FOR TC CLAMPS)
IBP
SPINDLE A B
For solid-arm clamps. Weld on bolt retainer at B PART NO. SIZE DIA DIA C
desired arm length and spindle angle. CL-1458-S 1/4-20 or M6 .257 5/8 5/8
CL-51658-S 5/16-18 or M8 .316 5/8 5/8
C
A DIA DRILL
CL-3878-S 3/8-16 or M10 .397 3/4 7/8

MOUNTING BRACKETS

11

(4) HOLES 11/64 DIA
FOR #8 OR M4 SCREWS

5/8
5/16
Downholding Push/Pull
IBP
5/8
IBP
15/16 5/16
15/32
Handy bracket for side-mounting small FITS FITS
clamps. One reversible bracket fits DOWNHOLDING PUSH
several clamps. 1/2 PART NO. CLAMPS CLAMPS
CL-150-VTC CL-50-SPC
CL-400-PCBR
CL-400-PTC CL-600-PPC
(3) HOLES 11/64 DIA
FOR #8 OR M4 SCREWS
