Especificaciones Ópticas

2700 K 3000 K

0.8 Max=5338 [1.0=20000] 3.50SDCM F2700K 0.8 Max=7171 [1.0=20000] 2.12SDCM F3000K
0.7 0.7
0.6 0.6
0.5 0.5
Distribución Spectrum 0.4 x=0.4464 y=0.4049 Spectrum 0.4 x=0.3841 y=0.3816
espectral 0.3 0.3
0.2 0.2
0.1 0.1
0.0 0.0
380 500 600 700 800 380 500 600 700 800
Wavelength(nm) Wavelength(nm)
-/+180 -/+180
-120 120 -120 120
0 0
-90 90 -90 90
500 500
Diagrama de 1000 1000
intensidad polar 1500 1500
2000 2000
2500 2500
-30 30 -30 30
0 0
UNIT: cd UNIT: cd
AVERAGE BEAM ANGLE(50%): 61.7 DEG AVERAGE BEAM ANGLE(50%): 61.9 DEG
Planar Illuminance Curve Planar Illuminance Curve
E(LX) MH=10m E(LX) MH=10m
25 C0/180 25 C0/180
C90/270 C90/270
22.5 22.5
20 20
17.5 17.5
Diagrama cartesiano 15 15
de intensidad 12.5 12.5
10 10
7.5 7.5
5 5
2.5 2.5
0 -25- 20 -15- 10 -5 05 10 15 20 25 0 -25- 20 -15- 10 -5 05 10 15 20 25
Distance(m) Distance(m)
Flux out: 907.3 lm Flux out: 1555 lm

3.281ft 94.90, 163.6fc 3.382ft 3.281ft 109.1, 211.9fc 4.168ft
1m 1022, 1761lx 103.09cm 1m 1174, 2281lx 127.03cm
6.562ft 23.73, 40.90fc 6.765ft 6.562ft 27.27, 52.97fc 8.335ft
2m 255.4, 440.3lx 206.19cm 2m 293.5, 570.2lx 254.06cm
Diagrama de haz 9.843ft 10.54, 18.18fc 309.28cm 9.843ft 12.12, 23.54fc 381.09cm
12.5ft
10.15ft
3m
3m
113.5, 195.7lx
130.4, 253.4lx
13.12ft 5.931, 10.23fc 13.53ft 13.12ft 6.817, 13.24fc 16.67ft
4m 63.85, 110.1lx 412.37cm 4m 73.38, 142.5lx 508.12cm
16.4ft 3.796, 6.544fc 16.91ft 16.4ft 4.363, 8.476fc 20.84ft
5m 40.86, 70.44lx 515.47cm 5m 46.96, 91.23lx 635.15cm
Height Eavg, Emax Angle: 60.54deg Diameter Height Eavg, Emax Angle: 59.84deg Diameter
Note: The Curves indicate the illuminated area and the average Note: The Curves indicate the illuminated area and the average
illumination when the Luminaire is at different distance. illumination when the Luminaire is at different distance.
