Especificaciones Ópticas

4000 K

0.8 Max=8699 [1.0=20000] 2.05SDCM F4000K
0.7
0.6
Distribución Spectrum 0.5 x=0.3473 y=0.3564
0.4
espectral 0.3
0.2
0.1
0.0
380 500 600 700 800
Wavelength(nm)
-/+180
-120 120
0
-90 90
900
Diagrama de 1800
intensidad polar 2700

3600
4500
-30 30
0
UNIT: cd
AVERAGE BEAM ANGLE(50%): 43.7 DEG
Planar Illuminance Curve
E(LX) MH=10m
45 C0/180
C90/270
40.5
36
31.5
Diagrama cartesiano 27
de intensidad 22.5
18
13.5
9
4.5
0
-25- 20 -15- 10 -5 051 01 52 02 5
Distance(m)
Flux out: 1774 lm

3.281ft 241.3, 395.3fc 2.926ft
1m 2598, 4255lx 89.20cm
6.562ft 60.33, 98.82fc 5.853ft
2m 649.4, 1064lx 178.40cm
Diagrama de haz 9.843ft 26.81, 43.92fc 267.59cm
8.779ft
3m
288.6, 472.8lx
13.12ft 15.08, 24.71fc 11.71ft
4m 162.4, 265.9lx 356.79cm
16.4ft 9.653, 15.81fc 14.63ft
5m 103.9, 170.2lx 445.99cm
Height Eavg, Emax Angle: 48.07deg Diameter
Note: The Curves indicate the illuminated area and the average
illumination when the Luminaire is at different distance.
