Page 71 - 2017 Product Guide

SPACE HEATING | THERMOFAN

2
thermogroup•warranty

The Thermofan TF1800 boasts the latest in intelligent energy saving controls, and its slimline
design and touchscreen controls make it a perfect addition to any modern home.
This Thermofan comes as standard with a cord and a 3-pin-plug which can come out either the
right or left hand side of the unit. If required, this plug can be can be removed by an electrician
and be hard wired in behind the unit.
The TF1800 Thermofan is fully programmable, allowing you to set when you want it on every day
of the week and at your desired temperature.
Alternatively, the automatic mode can be selected which allows you to set your comfort
temperature and the Thermofan will heat as required, using the presence sensor to maintain this
temperature. The presence sensor is designed to reduce energy consumption as it automatically
lowers the ambient temperature when no-one is detected in the room and comes back to the set
comfort temperature when movement is detected again.
TF1800 FEATURES

• Dimensions: H450 x W270 x D110mm • 2 Heating Modes
• 1800 Watts Output • Presence sensor on front of unit
• White / Grey faceplate • Designed to heat rooms from 10-20m²
• Safe and silent • IP24 protection rating
• Touchscreen controls • Made in Italy
• Fully programmable • 2 Year warranty

Touchscreen Removable Towel rail and
controls on and washable extra hooks for
face of unit filter concealed towels
behind unit

Thermofan Wall Mounted Bathroom Heaters

STOCK DESCRIPTION SIZE (H x W x D) OUTPUT ROOM SIZE RRP EXCL RRP INCL
NO MM W M² $ $
TF1800 Fan Heater with Presence Sensor 450 x 270 x 110 1800 10 - 20 271.82 299.00

The Thermofan TF2100 is designed to provide an instant heat source in bathrooms, kitchens or
other rooms of your home. The warm air is blown downwards from the underneath of the unit,
with the air intake at the front, thus creating less draughts and heating more efficiently.
The unit features a pre-set thermostat which will automatically reduce the output to 1000
Watts as soon as the room warms up. If required this Thermofan can be set to always operate at
1000 Watts rather than 2000 Watts, at time of installation.
This unit comes standard as a hard wired unit, however can be fitted with a lead and 3-pin-plug
by an electrician, enabling it to be plugged in if required.
The unit is extremely easy to operate as it has a simple pull cord that is used to turn the unit on
and off as required.
TF2100 FEATURES
• Dimensions: H245 x W237 x D130mm • 3 Heat Settings
• 2000 Watts Output • Thermal Overheat Cut Out Switch
• Easy to use • Designed to heat rooms from 10-20m²
• Pre-set Temperature • IP21 protection rating
• Pull Cord and Pilot Light • 2 Year warranty

Thermofan Wall Mounted Bathroom Heaters

STOCK DESCRIPTION SIZE (HxWxD) OUTPUT ROOM SIZE RRP EXCL RRP INCL
NO MM W M² $ $
TF2100 Fan Heater with Pull Cord 245 x 237 x 130 2000 10 - 20 140.91 155.00

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 71
