Page 67 - 2017 Product Guide

INSULATION | ECONOSPEED

Free floating sub floor for UFH

Econospeed is a free floating subfloor specially
designed for use over electric underfloor
heating systems such as Thermofoil PRO.
Ideal when laying vinyl or a floating timber
LAY SOFT FLOOR floor. (Not suitable for glued timber floors)
FINISHES ON TOP
5 Reasons to choose Econospeed
• 7mm buildup made of HDF board
• Dry overlay for electric heating systems
• Very low heat resistance - TOG 0.5
• Perfect finish for vinyl, carpet or cork
• Provides a clean, dust free substrate

Fast track floor finish
Econospeed is very simple to install and much
quicker and easier to use than a traditional
smoothing compound. It is also an entirely dry
process so it is much cleaner, faster and easier
than using the wet screed method.

Create a perfectly smooth surface for soft floor finishes!

Econospeed high performance HDF overlay system Only 7mm thick
The twin layers (3+4 mm HDF) of
STOCK DESCRIPTION PACK AREA UNIT RRP EXCL RRP INCL Econospeed, both provided with interactive
NO $ $
adhesive, utilise an overlap joint configuration
5420 7mm HDF Heating Overlay 2.88m 2 pk 235.45 259.00 to produce a seamless surface, immediately
ready to receive the floor covering.
Econospeed is supplied in packs of 8 (4 top boards and 4 base boards) with a coverage of 2.88m . 2

Installation method

1. Loose lay the Rigid Insulation Board
2. Roll out the Thermofoil heating mat
3. Lay Econosoft
4. Put down the first layer of Econospeed
5. Lay second layer of Econospeed
with overlapping joints by half
a board in both directions
6. Install your floor finish

Packaging information
• 1pk = 4 base boards and 4 top boards
with an area of 2.88m².
• 1 pallet = 48 packs (138.24m²)
• Pallet weight = 830kg

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 67
