M High performance machine taps

HRC60
ISO Metric coarse thread DIN-13
1 C-HM-TC C-IK-HM-TC D-HM-TC D-IK-HM-TC
0
S
H S 60 E l 1
HSSE
P
PM l 3
P
M
l 2
VHM
d 1 d 2 a
l 1
TC
TC l 2
DIN DIN
371 376
d 1 d 2 a

P M K P M K P M K P M K
Material groups
N S H N S H N S H N S H
Hole type
< 1,5d < 1,5d < 1,5d < 1,5d
Quality of material VHM VHM VHM VHM
Coating TC TC TC TC
Chamfer C / 2-3P C / 2-3P D / 4-5P D / 4-5P
Norm DIN-371
M
P l Ćd 2 a Tol. 6HX
Ćd l 1 l 2 3
1
INDEX C9-125F01 C9-125F51 C9-135F01 C9-135F51
M3 0,50 56 5 18 3,5 2,7 2,50 0030 - - -
M4 0,70 63 7 21 4,5 3,4 3,30 0040 - -
M5 0,80 70 8 25 6,0 4,9 4,20 0050 - -
M6 1,00 80 10 30 6,0 4,9 5,00 0060
M8 1,25 90 13 35 8,0 6,2 6,80 0080
M10 1,50 100 15 39 10,0 8,0 8,50 0100

Norm DIN-376
M l
Ćd P l 1 l 2 3 Ćd 2 a Tol. 6HX
1
INDEX D9-125F01 D9-125F51 D9-135F01 D9-135F51
M12 1,75 110 18 - 9,0 7,0 10,20 0120
M14 2,00 110 20 - 11,0 9,0 12,00 0140
M16 2,00 110 20 - 12,0 9,0 14,00 0160
ISO Vc (m/min)
P - - - -
M - - - -
-
-
-
-
K 1-60 5-60 1-60 5-60 5-60
N - - - - 10-30 10-30
S - - - -
H 1-4 1-4 1-4 1-4

Example of order Available from stock
28
C9-125F01-0030 On request
Tap HRC60 M3-6HX DIN-371 C VHM TC
