Anaerobic Gasket Makers & Flange Sealants Gasketing

Permatex Anaerobic Gasket Maker
®
OEM specified. Non-corrosive gasketing
material designed primarily for use on aluminum,
iron, and steel flanged mating surfaces. Ideal
when a conventional gasket is unavailable (not
for use with conventional gaskets). Fills gaps
up to .015” and cures to a solvent-resistant
seal that will not tear or decay during service.
Parts disassemble easily even after extended
service. Old gasket material can be removed
in minutes with the Permatex Safer Scraper.
Suggested Applications: For use on
machined aluminum metal components;
transmission pans, transmission case
covers, transaxle casings, transfer cases,
split crankcases, pumps, and housings.
Item # Container Size Pack
51813 50 ml tube, carded 6
51817 6 ml tube, carded 12
51845 300 ml cartridge 10

Permatex High Temperature
®
Anaerobic Flange Sealant
A high temperature sealant specially engineered
for machined surfaces in rigid assemblies. Able
to withstand temperatures to 400°F (204°C), fills
gaps up to 0.020” and permits clamping loads to
be maintained for strong, leakproof assemblies.
Suggested Applications: Water pumps,
thermostat housings, engine cases, timing
covers, transmission pans, transmission
case covers, and transaxle casings.

Item # Container Size Pack
51031 50 ml tube 10

Permatex Anaerobic Flange Sealant
®
Flexible, gasketing material for use on rigid
machined flanges with less than .015” gap.
OEM approved – use where OE’s specify
“anaerobic” gasket (cures in the absence of
air). Withstands temperatures to 300°F
(149°C). Eliminates preformed pre-cut,
paper, rubber and cork gaskets. Flexes
with flanges that move in service.
Suggested Applications: Water pumps,
thermostat housings, transmission pans,
transmission case covers, engine cases,
timing covers, and transaxle casings.
Item # Container Size Pack
51531 50 ml tube 10
51580 300 ml cartridge 10
