SECTION 5.0 – ARCHITECTURAL COMPONENTS, MATERIALS AND FINISHES SECTION 5.0 – ARCHITECTURAL COMPONENTS, MATERIALS AND FINISHES

i) Heavy duty coloured stamped or stencilled concrete or any other d) Timber skirting of 100 mm x 12 mm thick, chamfered at the top, shall
approved alternatives shall be used at driveways and car porches be provided to timber strip flooring and fixed securely to the wall or
unless otherwise specified. column.

j) Coloured concrete floor hardener shall be provided in areas of heavy e) Timber strips shall be regular, even, and consistent in size with sharp
machinery works. It shall be laid with a self-levelling epoxy floor well defined arises, matching colour, textured, grain, free from splits,
complete with floor hardener and crystallization or cementitious chips, and blemishes.
waterproofing. A proprietary floor hardener system shall be used and
applied following the manufacturer’s recommendation. Floor hardener f) The proprietary timber flooring system shall be following the
materials shall be of high quality, heavy-duty 5 mm thick above 150 mm manufacturer’s specifications.
thick concrete floor slab.
i. Solid Timber

5.3.9 Pavers Timber flooring shall be hardwood timber strips not less than 1200
mm x 18 mm thick. Timber flooring, where specified, shall be Group
a) Pavers shall be provided to areas needed as per functional C species according to JKR Standard Specifications for Building
requirement: Works.

i. Pre-cast concrete pavers shall be a minimum of 60 mm thick for light ii. Natural Timber Laminated
to a medium-duty application (e.g., footpaths, jogging tracks,
residential driveways). Natural timber flooring shall be 14.5 mm thick (15 mm finished)
made of three (3) ply engineered solid timber and excellent
ii. Pre-cast concrete pavers shall be a minimum of 80 mm thick for workmanship. The hardwood floor shall consist of three layers.
heavy-duty application (e.g., roads, factory floors, container yards, Each has a specific feature to complement each other, providing
aircraft parking aprons). Pavers, where specified, shall be of improved resistance to wear. The surface shall be treated with
approved equivalent and applied strictly following the seven (7) coats of UV lacquer, preferably pre-finished in the
manufacturer’s specification. factory, resulting in a more durable and hard-wearing finish.
iii. Laminated Composite Flooring
iii. Interlocking pavers shall be laid on sand bedding and lean concrete
and shall strictly comply to manufacturer’s specification. The Laminated composite flooring shall be of 8 mm thick pre-finished
contractor shall submit a method statement for the PD’s surface of anti-abrasive protective overlay according to the area’s
concurrence. function.

5.3.10 Timber Floor Finish 5.3.11 Carpet

a) All timber flooring works shall comply with the latest JKR Standard a) Carpet tiles or broadloom carpet shall be appropriate to the function of
Specification for Building Works. areas and shall comply to the latest Pekeliling Perbendaharaan
Malaysia WP 2.1 - Peraturan dan Had Harga Perabot/Kelengkapan
b) Timber flooring shall be provided to areas needed as per functional Bagi Pejabat Anggota-Anggota Perkhidmatan Awam Persekutuan
requirements. (Termasuk Anggota Polis Diraja Malaysia).

c) Timber floor finish shall be high-quality timber/laminated timber to be b) Carpet shall be provided to areas needed as per functional
laid on the rubberised cushioning pad on 20 mm thick cement screed requirements.
on a concrete slab with an approved waterproof adhesive applied
following manufacturer’s specifications. c) Carpet is not encouraged to be used in the Clinical Area. If required, the
type of carpet shall be hygienic and subject to the PD’s concurrence.
