SECTION 5.0 – ARCHITECTURAL COMPONENTS, MATERIALS AND FINISHES SECTION 5.0 – ARCHITECTURAL COMPONENTS, MATERIALS AND FINISHES

minimum of ten (10) years warranty from the date of CPC is required from Accessibility in Built Environment – Code of Practice. The successful
the manufacturer. tenderer shall provide mock-ups for the PD’s concurrence before
installation.
5.10.11 Clinical wash hand basin complete with 100 mm high backsplash and 6 mm
thick frameless beveled edge mirrors (450 mm x 600 mm) shall be provided c) Each of the WC shall be provided with chrome-plated fittings such as
at each patient bay and other clinical areas. The backsplash shall be high- adjustable control bidet/nozzle spray at 1.2 meters long and fixed on
pressure laminated phenolic board with a minimum size (800 mm x 1700 the right side of the wall, complete with stainless steel grade 304 top
mm x 10 mm thick) to accommodate soap dispensers. The backsplash shall cover tissue roll holder, heavy-duty seamless, flexible hose with wall
be installed with a minimum of 300 mm height from the finished floor level. hook fittings and a toilet holder.

5.10.12 All basins with hot and cold water for the clinical area shall have stainless d) All squatting WC shall have an integral footrest and a water seal trap,
steel P-traps unless otherwise specified. if required.

5.10.13 Stainless steel scrub-up troughs shall be provided in Operation Theatres e) Except for the siphonic system, all other flushing cisterns shall be
Department and all other clinical areas where deemed necessary. The designed in such a way to give dual flushes with a nominal volume of
scrub-up troughs shall be installed complete with a minimum of 550 mm a full and partial flush not exceeding 6 and 3 litres, respectively,
high backsplash, lever handle/knee operated taps and foot-operated soap following the Water Services Industry Act 2006.
dispensers, bevel edges standing height mirror, brush dispensers, and
brush-collection basket. The tenderer shall prepare a mock-up to determine f) The concealed cisterns shall be installed per the manufacturer’s
the actual dimension between tap outlets and finish floor level to the PD’s mounting instructions and other relevant recommendations. A ten (10)
concurrence before installation. years warranty from the manufacturer shall be provided for all the
concealed cisterns, and the warranty period shall start from the date of
5.10.14 All countertops/worktops with integral sinks shall be 15 mm thick handing over.
impermeable, monolithic, and chemical resistant solid surface moulded with
100 mm bullnose backsplash. The backsplash must be properly sealed at g) An easily accessible service opening shall be provided for WC using
the joints with the wall to prevent water seepage. The size of the backsplash the flush valve system. A service room with a minimum clear width of
shall be the full length of the countertop. 900 mm shall be provided to allow for easy access during maintenance
of the pipes.
5.10.15 Unless otherwise described plaster traps of the stainless steel with
minimum grade 304 shall be provided for the sinks at the Plaster Room or h) No urinals shall be installed.
any other clinical areas involving plastering works to avoid blockage of
drainage pipes. The design shall comply with Garis Panduan Konsep i) Wherever WC for the children’s convenience is required, the standard
Rekabentuk Dan Pemasangan Dental Wax dan Plaster Trap Di Makmal WC shall be used and shall be installed slightly lower than the standard
Pergigian by the MOH. Shop drawings shall be submitted for the PD’s WC. For paediatric WC, it shall be supplied with an adaptor.
approval.

5.10.16 A suitable type of hangers for lead gowns shall be fixed securely to the wall 5.10.18 Wash Hand Basin
in the radiology area, imaging area, and as to where required.
a) All wash hand basins and countertops (excluding clinical wash hand
basins, laboratory sinks, stainless steel sinks, and scrub-up troughs)
5.10.17 Water Closets (WC) shall be provided with appropriately sized mirrors, which shall be fixed
flush to the walls.
a) Wall hung, pedestal, and squatting types of WC shall be made of
vitreous china. b) Countertops made of an approved solid surface shall have both
integral, wash hand basins and 100 mm high backsplash or shall have
b) The top of the toilet seat shall be optimized at 460 mm from the finished under-counter vitreous china wash hand basins.
floor level and comply with MS 1184: 2014 Universal Design and

50 51
