6. On the diagrams that you have drawn in steps 4 and 5, draw three antinodal lines and
two nodal lines.
Discussion:
1. Based on the patterns of interference A and B, describe the difference in the pattern of
interference when the distance of separation between sources increases.
2. Based on the patterns of interference A and C, describe the difference in the pattern of
interference when wavelength increases.
3. How does the distance between antinodal lines change at positions further from the
coherent sources?

Relationship between Variables of Interference of Waves
In the pattern of interference of waves, there are four variables namely λ, a, x and D which are
related to the interference pattern of waves.

λ = wavelength
a = distance of separation between two coherent sources
x = distance of separation between two adjacent antinodal lines or two
adjacent nodal lines
D = the perpendicular distance from the sources and the position where the
value of x is measured

Activity 5.21 Algorithms ICS

Aim: To study the relationship between λ, a, x and D
Instructions:
1. Work in pairs.
2. You are given three patterns of interference of waves in Figure 5.64.

S
1
S S
1 1 x
x
x
a a a

S S
2 2
S
2
D D D

Pattern 1 Pattern 2 Pattern 3
Figure 5.64 Pattern of interference of waves
