Page 234 - Deko-Light Light Impressions 2019-20
P. 234
Ra >90
COB-68-350MA-2700K-ROUND
aluminium
dimensions H x Ø: 46 x 78 mm
dimmable via optionales power supply
power input: 6,00 W
energy efficiency class [EEI] spectrum A ++ to E
565278 silver coloured brushed WW 2700 K 580 lm EEI: A++
565279 white WW 2700 K 580 lm EEI: A++
565280 silver coloured brushed NW 4000 K 660 lm EEI: A++
565281 white NW 4000 K 660 lm EEI: A++
1
CC 350 mA 16-17 6 W COB LED Ra>90 45° 25° 68 50
accessories
180512 power supply | 350 mA | 18 W
872642 power supply dimmable | 350 mA | 9 W
Ra >90
COB-68-350MA-2700K-ANGULAR
aluminium
dimensions L x W x H: 78 x 78 x 46 mm
dimmable via optionales power supply
power input: 6,00 W
energy efficiency class [EEI] spectrum A ++ to E
565282 silver coloured brushed WW 2700 K 580 lm EEI: A++
565283 white WW 2700 K 580 lm EEI: A++
565284 silver coloured brushed NW 4000 K 660 lm EEI: A++
565285 white NW 4000 K 660 lm EEI: A++
16-17 1
CC 350 mA 6 W COB Ra>90 45°
LED
25° 68 50
accessories
180512 power supply | 350 mA | 18 W
872642 power supply dimmable | 350 mA | 9 W
INTERIOR LAMPS | recessed ceiling built-in lamps | transversable 233
