Page 239 - Deko-Light Light Impressions 2019-20
P. 239
Ra >90
COB-68-24V-2700K-ROUND
aluminium diecast
dimensions H x Ø: 36 x 85 mm
dimmable via optionales power supply
power input: 4,50 W
energy efficiency class [EEI] spectrum A ++ to E
565299 silver coloured brushed WW 2700 K 330 lm EEI: A+
565300 white WW 2700 K 330 lm EEI: A+
565301 silver coloured brushed NW 4000 K 370 lm EEI: A++
565302 white NW 4000 K 370 lm EEI: A++
24 1
CV 4,50 W COB Ra>90 45°
LED
30° 68 34,00
accessories
872630 power supply | 24V DC | 6 W
872636 power supply | 24V DC | 20 W
862052 power supply dimmable | 24V DC | 25 W
843022 RF-controller RGB dimmable | 12 - 24V DC | max. 360 W
Ra >90
COB-95-24V-2700K-ROUND
aluminium diecast
dimensions H x Ø: 55 x 115 mm
dimmable via optionales power supply
power input: 12,00 W
energy efficiency class [EEI] spectrum A ++ to E
565307 silver coloured brushed WW 2700 K 900 lm EEI: A+
565308 white WW 2700 K 900 lm EEI: A+
565309 silver coloured brushed NW 4000 K 1000 lm EEI: A+
565310 white NW 4000 K 1000 lm EEI: A+
24 1
CV 12 W COB Ra>90 45°
LED
30° 95 53,00
accessories
872636 power supply | 24V DC | 20 W
862054 power supply dimmable | 24V DC | 50 W
843022 RF-controller RGB dimmable | 12 - 24V DC | max. 360 W
238 INTERIOR LAMPS | recessed ceiling built-in lamps | transversable
