Page 246 - Deko-Light Light Impressions 2019-20
P. 246
Ra >90
UNI II MINI
aluminium diecast
dimensions H x Ø: 80 x 103 mm
dimmable via optionales power supply
power input: 9,00 W
energy efficiency class [EEI] spectrum A ++ to E
565342 white WW 3000 K 670 lm EEI: A+
1
CC 500 mA 18-19 9 W COB LED Ra>90 33° 75 ° 90 85
accessories
930331 reflector ring black
930332 reflector ring gold
930333 reflector ring chrom
930381 reflector ring II black
930329 cover heatsink black
862030 power supply dimmable | 500 mA | 12 W
180513 power supply | 500 mA | 15 W
Ra >90
UNI II MAX
aluminium diecast
dimensions H x Ø: 97 x 165 mm
dimmable via optionales power supply
power input: 24,00 W
energy efficiency class [EEI] spectrum A ++ to E
565344 white WW 3000 K 2150 lm EEI: A+
1
CC 700 mA 34-35 24 W COB LED Ra>90 33° 85 ° 155 100
accessories
930398 reflector ring black
930399 reflector ring gold
930382 reflector ring II black
930396 cover heatsink black
930390 reflector 24°
930392 reflector 50°
862035 power supply dimmable | 700 mA | 36 W
872662 power supply | 700 mA | 30 W
INTERIOR LAMPS | recessed ceiling built-in lamps | transversable 245
