WALL WASHER CAPH SYMMETRIC
aluminium diecast
dimensions L x W x H: 1000 x 53,36 x 81,07 mm
dimmable via optional controller
energy efficiency class [EEI] spectrum A ++ to E
732065 dark gray WW 3000 K 1CH 40 W 2560 lm EEI:A
732067 dark gray NW 4000 K 1CH 40 W 3200 lm EEI: A+
732073 dark gray WW CW 1800-5500 K 2CH 66 W 3700 lm EEI: A
732069 dark gray RGB 3CH 54 W 2150 lm EEI: A
732071 dark gray RGB WW 3000 K 4CH 60 W 2800 lm EEI: A
24 SMD LED Ra>80 25° IP65
24
suitable power supplies 722
suitable power supply IP67 from page 725
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
WALL WASHER CAPH ASYMMETRIC
aluminium diecast
dimensions L x W x H: 1000 x 53,36 x 81,07 mm
dimmable via optional controller
energy efficiency class [EEI] spectrum A ++ to E
732066 dark gray WW 3000 K 1CH 40 W 2570 lm EEI: A
732068 dark gray NW 4000 K 1CH 40 W 2800 lm EEI: A
732070 dark gray RGB 3CH 54 W 1900 lm EEI: A
732072 dark gray RGB WW 3000 K 4CH 60 W 2480 lm EEI: A
24 SMD LED Ra>80 40° / 15° IP65
24
suitable power supplies 722
suitable power supply IP67 from page 725
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
484 OUTDOOR LAMPS | wall washer
