Page 483 - Deko-Light Light Impressions 2019-20
P. 483
MINI WALL WASHER I
aluminium diecast
dimensions L x W x H: 505 x 47 x 54 mm
dimmable via optional controller
power input: 7,30 W
energy efficiency class [EEI] spectrum A ++ to E
732019 silver coloured WW 3000 K 540 lm EEI: A
24 12
7,30 W LED Ra>80 36° 90° IP65
accessories
862052 power supply dimmable | 24V DC | 25 W | IP20
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
MINI WALL WASHER II
aluminium diecast
dimensions L x W x H: 1005 x 27 x 54 mm
dimmable via optional controller
power input: 14,70 W
energy efficiency class [EEI] spectrum A ++ to E
732022 silver coloured WW 3000 K 1040 lm EEI: A
24 14,70 W 24 Ra>80 36° IP65
LED 90°
accessories
872658 power supply dimmable | 24V DC | 36 W
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
482 OUTDOOR LAMPS | wall washer
