ASSEMBLY FOR PROFILES & STRIPES
Upon request, we provide our products individually to measure.
Prices are available on request.

989100 – Service-Pack I – Cutting Profile
Cutting Profile, tolerance ± 1mm | awing losses 4mm

989200 – Service-Pack II – Cutting Cover
Cutting Cover, tolerance ± 1mm | awing losses 4mm

989300 – Service-Pack III – Cutting LED-Stripe
Cutting LED-Stripe, Soldering a connection line
[Dimensions & quantity, strip length & possibility to cut]

989400 – Service-Pack IV – Assembly complete luminaire
[requires service pack I, II, III]
Complete lamp assembly of profile, LED-Stripe 1 -2 | 3 - 4 channel, 12V | 24V,
Cover, end caps, bore in profile or end cap for cable passage.
Please take the cutting dimension of the LED-Stripe segment length plus 3 cm
or the junction box into account. Lengthwise tolerance ± 3mm

Cables – Maximum cable lengths for LED stripe supply lines
12 V max. 3 m to 100 W of power
24 V max. 5 m to 100 W of power
[Billing takes place according to meters per order]

989305 1 channel Connecting cable 1 channel
989310 2 channel Connecting cable 2 channel
989315 3 - 4 channel Connecting cable 3 - 4 channel
989320 1 - 4 channel Connecting cable MINI 1 - 4 channel

Options

989301 Connecting cable Attaching a 2nd connecting cable for further connection

989302 Connecting line Fixing of a connecting line between 2 stripe pieces,
incl. solder points on the left and right. Original length of
the stripe may not be exceeded by the individual parts.
989450 IP extra charge Process / Seal IP65 / Nano Stripes
989900 RAL Painting Coating the profiles in the desired RAL tone

Grouting We offer different types of casting, the prices for
which we have to determine individually. We look forward to your inquiry.
