Page 723 - Deko-Light Light Impressions 2019-20
P. 723
KAPEGO POWER SUPPLY | DESIGN ROUND
dimensions H x Ø: 22 x 53 mm
short-circuit proof and overload protection
862120 black 12V 8W 0-67A
872627 black 24V 8W 0-0,34A
110-240 8 M M
CV
KAPEGO POWER SUPPLY | DESIGN FLAT
short-circuit proof and overload protection
872629 black 12V 6W 0,50A 98 x 46 x 11 mm
872632 black 12V 12W 1,00A 128 x 50 x 13 mm
872635 black 12V 20W 1,67A 154 x 50 x 14 mm
862121 black 12V 50W 4,16A 185 x 62 x 22 mm
872630 black 24V 6W 0,25A 98 x 46 x 11 mm
872633 black 24V 12W 0,50A 128 x 50 x 13 mm
872636 black 24V 20W 0,83A 154 x 50 x 14 mm
862122 black 24V 50W 4,16A 185 x 62 x 22 mm
220-240 max 50 M M
CV
KAPEGO POWER SUPPLY | DESIGN BASIC
short-circuit proof and overload protection
overheat control
872657 black 12V 36W 3,00A 166 x 52 x 24 mm
872659 black 12V 50W 4,20A 184 x 61 x 32 mm
862127 black 12V 75W 6,30A 184 x 61 x 32 mm
862055 black 12V 100W 8,30A 184 x 61 x 32 mm
872658 black 24V 36W 1,50A 166 x 52 x 24 mm
872660 black 24V 50W 2,00A 184 x 61 x 32 mm
872661 black 24V 75W 3,00A 184 x 61 x 32 mm
862056 black 24V 100W 4,20A 184 x 61 x 32 mm
110-240 CV max 100 M M
722 POWER SUPPLY | DC | indoor | constant voltage
