Page 727 - Deko-Light Light Impressions 2019-20
P. 727
HEP POWER SUPPLIES LEXV SERIES
aluminium diecast housing
short-circuit and open-circuit proof
overload protection
872053 anthracite 12V 18W 1,50A 162 x 37 x 25 mm
872054 anthracite 12V 40W 3,34A 232 x 36,6 x 25 mm
872055 anthracite 12V 100W 8,3A 202 x 71,2 x 45 mm
872058 anthracite 24V 18W 0,75A 162 x 37 x 25 mm
872059 anthracite 24V 40W 1,67A 232 x 36,6 x 25 mm
872061 anthracite 24V 150W 6,00A 244 x 71,2 x 45 mm
110-240 max 150
CV IP67
MEANWELL POWER SUPPLIES LPV/LPH-SERIE
housing made of flame-retardant plastic
and completely potted according to 94V-0
short-circuit proof
872610 white 12V 18W 1,50A 140 x 30 x 22 mm
872612 white 12V 35W 3,00A 148 x 40 x 30 mm
872614 white 12V 60W 5,00A 162,5 x 42,5 x 32 mm
872616 white 12V 100W 8,50A 190 x 52 x 37 mm
872611 white 24V 18W 0,75A 140 x 30 x 22 mm
872613 white 24V 35W 1,50A 148 x 40 x 30 mm
872615 white 24V 60W 2,50A 162 x 42 x 32 mm
872617 white 24V 100W 4,20A 190 x 52 x 37 mm
110-240 CV max 100 IP67
726 POWER SUPPLY | DC | outdoor | constant voltage
