Page 766 - Deko-Light Light Impressions 2019-20
P. 766
You would like to dimming and switching 230V components universal dimmer switches are ideal for easy and problem-
from several locations, but do not have the required num- free integration of both existing and new installations.
ber of cores in the existing installation? Then the following
ELTAKO DIMMER UNIVERSAL 400W EUD12NPN-UC
control via standard pushbutton
[control voltage 10V-230V AC + DC]
short keys [on / off], long keys [dimming 0-100-0%]
suitable for R-L-C loads up to 400W, high voltage LEDs
up to 100W, automatic load detection, memory-function,
adjustable minimum load and dimming speed
dimensions L x W x H: 20 x 90 x 70 mm
843042 blue
220-240 max 400
ELTAKO DIMMER UNIVERSAL 400W EUD61NPN-UC
control via standard pushbutton
[control voltage 10V-230V AC + DC]
short keys [on / off], long keys [dimming 0-100-0%]
suitable for R-L-C loads up to 400W, high voltage LEDs
up to 100W, automatic load detection, memory-function,
adjustable minimum load and dimming speed
installation in junction box possible
dimensions L x W x H: 45 x 45 x 18 mm
843043 blue
220-240 max100/
400 W
ELTAKO SCHALTAKTOR-SET WITH FUNKTASTER
control via standard pushbutton
[control voltage 10V-230V AC + DC]
or freely positionable wireless pushbutton
short keys [on / off], long keys [dimming 0-100-0%]
suitable for R-L-C loads up to 300W, high voltage LEDs
up to 100W, automatic load detection, memory-function,
adjustable minimum load and dimming speed
dimensions dimmer L x W x H: 45 x 45 x 18 mm
843032 blue / white
220-240 max100/
300 W
ACCESSORIES | indoor | dimming 765
