Page 782 - Deko-Light Light Impressions 2019-20
P. 782
CABLE CONNECTOR | 2 POLE PITCH
CABLE CONNECTOR | 1 POLE PITCH
polycarbonate
polycarbonate appropriate to cable strand 0,3 - 0,75 mm 2
appropriate to cable strand 0,3 - 0,75 mm 2 no dismantle required
no dismantle required assembly according to custom and usage gripper
assembly according to custom and usage gripper dimensions L x W x H: 25 x 10,4 x 6,65 mm
dimensions L x W x H: 25 x 7 x 6,65 mm unsuitable to connect current stabilising components [CC]
packaging unit: 10 pcs. packaging unit: 10 pcs.
930226 black 930228 black
max 300 max 10 max 300 max 10
Volt A Volt A
CABLE CONNECTOR | 1 POLE PITCH | CABLE CONNECTOR | 2 POLE PITCH |
T-CONNECTOR T-CONNECTOR
polycarbonate polycarbonate
appropriate to cable strand 0,3 - 0,75 mm 2 appropriate to cable strand 0,3 - 0,75 mm 2
no dismantle required no dismantle required
assembly according to custom and usage gripper assembly according to custom and usage gripper
dimensions L x W x H: 25 x 12,8 x 6,65 mm dimensions L x W x H: 28,6 x 16,6 x 6,65 mm
unsuitable to connect current stabilising components [CC] unsuitable to connect current stabilising components [CC]
packaging unit: 10 pcs. packaging unit: 10 pcs.
930227 black 930229 black
max 300 max 10 max 300 max 10
Volt A Volt A
ACCESSORIES | indoor | high voltage 781
