Page 494 - Deko-light Catalogue 2022
P. 494
LED PANEL SQUARE 8
aluminium diecast
dimensions L x W x H: 110 x 110 x 23,5 mm
dimmable via optinional power supply unit
565152 Signal white RAL 9003 WW 2700 K 560 lm 34,95 €
565153 Pearl light grey RAL 9022 WW 2700 K 560 lm 34,95 €
565154 Signal white RAL 9003 NW 4000 K 560 lm 34,95 €
565155 Pearl light grey RAL 9022 NW 4000 K 560 lm 34,95 €
18
CC 350 mA 18-19 7 W SMD LED Ra>80 110° 90x90 20
accessories
872631 power supply | 350 mA | 2-35V | 0,7-12,0 W 21,95 €
862202 power supply dimmable | 350 mA | 11-26V | 3,9-9,0 W 28,95 €
862190 power supply MULTI-CC DALI1/2/Intelli-Push dimmable | 15-34V | 4,2-12,0 W 59,95 €
LED PANEL SQUARE 15
aluminium diecast
dimensions L x W x H: 180 x 180 x 21 mm
dimmable via optinional power supply unit
565156 Signal white RAL 9003 WW 2700 K 1000 lm 49,95 €
565157 Pearl light grey RAL 9022 WW 2700 K 1000 lm 49,95 €
565158 Signal white RAL 9003 NW 4000 K 1130 lm 49,95 €
565159 Pearl light grey RAL 9022 NW 4000 K 1130 lm 49,95 €
36
CC 350 mA 36-37 13 W SMD LED Ra>80 110° 155x155 20
accessories
180512 power supply | 350 mA | 2-52V | 0,7-18,0 W 23,95 €
862204 power supply dimmable | 350 mA | 28-57V | 9,8-20,0 W 39,95 €
862191 power supply MULTI-CC DALI1/2/Intelli-Push dimmable | 20-60V / 7,0-20,0 W 64,95 €
492 COMMERCIAL LIGHTS | built in ceiling lights
