Page 491 - Deko-light Catalogue 2022
P. 491
Ra
UNI II MINI
aluminium diecast
dimensions H x Ø: 80 x 103 mm
dimmable via optinional power supply unit
565342 Signal white RAL 9003 WW 3000 K 670 lm 89,95 €
1
CC 500 mA 18-19 9 W COB LED Ra>90 33° 75 ° 90 85
accessories
930331 reflector ring black 9,95 €
930332 reflector ring gold 9,95 €
930333 reflector ring chrom 9,95 €
930381 reflector ring II black 9,95 €
930329 cover heatsink black 2,95 €
180513 power supply | 500 mA | 2-38V | 1,0-18,0 W 23,95 €
862030 power supply dimmable | 500 mA | 12-24V | 6,0-12,0 W 29,95 €
862190 power supply MULTI-CC DALI1/2/Intelli-Push dimmable | 15-24V | 7,5-12,0 W 59,95 €
Ra
UNI II MAX
aluminium diecast
dimensions H x Ø: 97 x 165 mm
dimmable via optinional power supply unit
565344 Signal white RAL 9003 WW 3000 K 2150 lm 129,95 €
1
CC 700 mA 34-35 24 W COB LED Ra>90 33° 85 ° 155 100
accessories
930398 reflector ring black 9,95 €
930399 reflector ring gold 9,95 €
930382 reflector ring II black 9,95 €
930396 cover heatsink black 3,95 €
930390 reflector 24° 9,95 €
930392 reflector 50° 9,95 €
862198 power supply | 700 mA | 21-43V | 14,7-30,0 W 25,95 €
862208 power supply dimmable | 700 mA | 28-56V | 19,6-40,0 W 49,95 €
862192 power supply MULTI-CC DALI1/2/Intelli-Push dimmable | 25-64V | 17,5-45,0 W 69,95 €
COMMERCIAL LIGHTS | built in ceiling lights 489
