Page 543 - Deko-light Catalogue 2022
P. 543
UGR
D PROFESSION DOWN
powerful light output
UGR <19
ideal for home office or dining / living area
aluminium
dimensions L x W x H: 1177 x 53 x 53 mm
socket L x W x H: 560 x 65 x 38 mm
max. suspension: 3000 mm
+ POWER SUPPLY TRIAC
dimmable via leading or trailing edge
if required, by purchasing a corresponding base
can be converted to DALI or 1-10V dimmable at any time
620107 white NW 4000 K 3165 lm 329,90 €
620110 silver coloured NW 4000 K 3165 lm 329,90 €
620103 black NW 4000 K 3165 lm 329,90 €
+ POWER SUPPLY 1-10V
dimmable via 1-10V
if required, by purchasing a corresponding base
can be converted to DALI oder Triac dimmable at any time
620106 white NW 4000 K 3165 lm 339,90 €
620109 silver coloured NW 4000 K 3165 lm 339,90 €
620102 black NW 4000 K 3165 lm 339,90 €
+ POWER SUPPLY DALI
dimmable via DALI-Bus according to IEC 62386 DALI 1.0
if required, by purchasing a corresponding base
can be converted to TRIAC oder 1-10Vdimmable at any time
620105 white NW 4000 K 3165 lm 359,90 €
620108 silver coloured NW 4000 K 3165 lm 359,90 €
620057 black NW 4000 K 3165 lm 359,90 €
120
200-240 28 W SMD LED Ra>80 24°
90 90 90 90 90 90
500 500 500
1500 1500 1500
60 60 60 60 60 60
2500 2500 2500
3500 3500 3500
30 30 30 30 30 30
C0-180 4594 C0-180 4594 C0-180 4594
C90-270 0 C90-270 0 C90-270 0
light distribution curve 620107 light distribution curve 620106 light distribution curve 620105
COMMERCIAL LIGHTS | pendant lamps 541
