P. 614
EMERGENCY LIGHT ALMACH
FOR THE ILLUMINATION OF CORRIDORS
Red Dot Award Winner 2017
special lens for the illumination of escape routes
or for area lighting
plastic
dimensions L x W x H: 192 x 101 x 57 mm
single battery technology with LiFePO4 battery
SK II / III with INSiLIA technology
3h/8h bridging time
simple click mounting
rotatable
731142 white NW 4500 K 225,95 €
230
1 W LED IP42
PHOTOMETRIC DATA
a b c d c d
area lighting emergency exit lens
mounting height 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W
2,5 m 3,50 3,92 7,84 8,84 2,72 3,03 6,05 7,00 5,02 5,77 11,54 13,46
3,0 m 3,78 4,37 9,09 9,82 3,05 3,52 6,79 7,83 5,55 6,33 12,65 14,60
3,5 m 3,97 4,93 9,85 11,04 3,33 3,83 7,66 8,52 5,98 7,07 14,15 16,26
4,0 m 3,81 5,24 10,48 12,16 3,56 4,09 8,18 9,41 6,32 7,75 15,50 17,74
4,5 m - 5,50 10,99 13,19 3,73 4,45 8,90 10,24 6,12 8,37 16,74 19,09
5,0 m - 5,50 11,00 14,14 3,87 4,62 9,56 11,00 - 8,57 - 20,30
5,5 m - - - 15,00 - 4,91 - 11,69 - 8,72 - 21,39
6,0 m - - - 15,23 - 5,17 - 12,32 - 8,82 - 22,38
6,5 m - - - 15,37 - 5,41 - 12,90 - 8,56 - 23,27
7,0 m - - - 15,99 - 5,43 - 13,42 - - - -
7,5 m - - - 15,98 - 5,61 - 13,89 - - - -
