Page 616 - Deko-light Catalogue 2022
P. 616
EMERGENCY LIGHT ALNAIR
FOR THE ILLUMINATION OF AREAS
special lens for the illumination of escape routes
or for area lighting
plastic
dimensions H x Ø: 28 x 78 mm
single battery technology with LiFePO4 battery
SK II / III with INSiLIA technology
3h/8h bridging time
565326 white NW 4500 K 239,95 €
230
1 W LED 68 IP42
PHOTOMETRIC DATA
a b c d c d
area lighting emergency exit lens
mounting height 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W 1 W 2 W
2,5 m 3,57 4,00 8,00 9,02 2,68 3,09 6,17 7,14 5,13 5,62 11,78 13,74
3,0 m 3,84 4,45 9,24 9,99 3,11 3,45 6,90 7,96 5,64 6,43 12,87 14,85
3,5 m 3,89 5,00 10,00 11,20 3,38 3,89 7,77 8,64 6,06 7,18 14,35 15,72
4,0 m 3,73 5,13 10,62 12,32 3,48 4,14 8,28 9,53 6,16 7,85 15,70 17,16
4,5 m 2,00 5,56 11,11 13,34 3,78 4,50 9,00 10,35 - 8,12 - 19,30
5,0 m 1,92 5,55 11,11 14,28 3,91 4,66 9,66 11,11 - 8,66 - 20,50
5,5 m - 5,50 - 14,60 - 4,95 - 11,80 - 8,80 - 21,59
6,0 m - - - - - - - - - - -
6,5 m - - - - - - - - - - -
7,0 m - - - - - - - - - - -
7,5 m - - - - - - - - - - -
614 COMMERCIAL LIGHTS | emergency lights
