P. 633
D LINE T-JOINT LEFT-LEFT-RIGHT
WITH EXCHANGE MECHANISM
plastic
dimensions L x W x H: 166 x 101 x 35,50 mm
suitable for mounting and built in system
710027 Traffic white RAL 9016 41,95 €
710028 Window grey RAL 7040 41,95 €
710029 Graphite black RAL 9011 41,95 €
220-240 16 A IP20
D LINE T-JOINT RIGHT-RIGHT-LEFT
WITH EXCHANGE MECHANISM
plastic
dimensions L x W x H: 166 x 101 x 35,50 mm
suitable for mounting and built in system
710030 Traffic white RAL 9016 41,95 €
710031 Window grey RAL 7040 41,95 €
710032 Graphite black RAL 9011 41,95 €
220-240 16 A IP20
accessories for built in system
710093 cover plate built in track T-joint 2,95 €
Almost identically to the corner connector, the direction alignment. But also with this article, the variants could be
[left/right] of the T-connector can also be changed by remo- reduced by half. This also means here: significantly simpli-
ving the cover. Due to the design, however, there are two fied planning and assembly.
T-connectors in each colour variant, as it may be that either
left/left/right or right/right/left is required depending on the
POWER RAIL | D LINE power rail system 631
