HIGH LUMEN PACKAGE
Lumen+
Luminaires with high lumen values are ideal for illuminating
rooms or corridors. With the right wall luminaires, you can
achieve the prescribed lux values for corridors [100 lux] in
many cases without additional ceiling lighting.

WHAT IS HOW BRIGHT? HOW MANY LUMENS CORRESPOND
How many lumens do different lamps shine with? HOW MANY WATT?
Luminous efficacy is measured in lumens per watt [lm/W]
candle ~ 12 lm and indicates how efficiently a lamp shines and how energy
100W incandescent bulb ~ 1.340 lm is converted into light.
40W fluorescent lamp ~ 3.000 lm
guide values:
incandescent bulb approx 10 lm/W
halogen lamp approx 20 lm/W
fluorescent lamp approx 70-90 lm/W
LED lamp approx 60-170 lm/W

WHERE DO I NEED HOW MANY LUMENS? WHAT DOES "LUX" MEAN?
You should plan for these lumens per square metre, Lux [lx] is the physical unit of the illuminance of a light source.
so that your home is optimally and comfortably illuminated: This photometric quantity indicates how much luminous
flux from a light source falls on a given surface.
guide values:
living room approx 140 lm/m² Of course, the following values do not have to be achieved
bedroom approx 140 lm/m² in the entire room.
children's room approx 140 lm/m²
hallway approx 140 lm/m² guide values:
study approx 280 lm/m² bedroom 45 Lux
kitchen approx 280 lm/m² living room 77 Lux
bathroom approx 280 lm/m² bathroom 110 Lux
hallway 207 Lux
study/office 300 Lux [at desk: 500 Lux]

IK-VALUE

In addition to the IP protection class, you should also keep There are eleven codes, corresponding to the impact energy
an eye on the IK value of a luminaire, which is increasingly that a enclosure can withstand. [Source: wikipedia.org]
required within the scope of tenders and for installations
in public spaces. The IK value [or IK impact resistance le- code impact energy corresponds to drop height
vel] indicates how impact-resistant a luminaire or certain in joules in mass
components are. IK00 offers no protection against external IK00 no protection
mechanical stress, IK10 or IK10+ means that the luminaire
can withstand a 5 or 10 kg test weight from a distance of IK01 0,14 7 cm - 200 g
40 or 50 cm.
IK02 0,20 8 cm - 250 g
IK03 0,35 14 cm - 250 g
IK04 0,50 20 cm - 250 g
IK05 0,70 28 cm - 250 g
IK06 1,0 40 cm - 250 g
IK07 2,0 40 cm - 500 g
IK08 5,0 25 cm - 2000 g
IK09 10,0 20 cm - 5000 g
IK10 20,0 40 cm - 5000 g
IK10+ 50,0 50 cm - 10000 g

06 LIGHT IMPRESSIONS | information
