Page 95 - ARC KATALOG

Accessory

ARC6608
DMX Distributor
Dimension 96 mm(L) x 48 mm(W) x 28.5 mm(H)
6608 Input Signal (Standard RS485 differential signal)
1 group DMX+ / DMX512

Output Signal 4 sets DMX+ / DMX512
(Standard RS485 differential signal)
Transmission
ARC6608 DMX Distributor distance Max. 100 m
IP Rating IP66
ARC6608-W0/C0/M0 Distributor distributes DMX512
or DMX+ signals of ARC SSL's DMX controller into 4 Opearing Temperature: -20 ~ 60Ċ
IP Rating
outputs. Opearing Humidity: 10%~90%

94 OutDoor Lighting
