MODUL • Fizik TINGKATAN 5

Eksperimen Untuk menentukan kekuatan elektromagnet
Experiment
To determine the strength of an electromagnet

Mengkaji hubungan antara kekuatan Mengkaji hubungan antara kekuatan elektromagnet
elektromagnet dengan arus dengan bilangan lilitan solenoid
To investigate the relationship between the strength of To investigate the relationship between the strength of an
an electromagnet and the current electromagnet and the number of turns of the solenoid
Kekuatan elektromagnet bergantung kepada Kekuatan elektromagnet bergantung pada bilangan lilitan
Inferens magnitud arus elektrik. solenoid.
Inference The strength of an electromagnet depends on the The strength of an electromagnet depends on the number of
magnitude of the current. turns of solenoid.

Kekuatan elektromagnet (berdasarkan bilangan Kekuatan elektormagnet (berdasarkan bilangan paku yang
paku yang terlekat kepada elektromagnet) terlekat kepada elektromagnet) bertambah apabila bilangan

Hipotesis bertambah apabila arus elektrik bertambah. lilitan solenoid bertambah.
Hypothesis The strength of an electromagnet (indicated by the The strength of an electromagnet (indicated by the number
number of nails attached to the electromagnet) of the nails attached to the electromagnet) increases as the
increases as the current increases. number of turns of solenoid increases.

Untuk mengkaji hubungan antara kekuatan Untuk mengkaji hubungan antara kekuatan elektromagnet
Tujuan elektromagnet dan arus. dan bilangan lilitan solenoid.
Aim To investigate the relationship between the strength of To investigate the relationship between the strength of an UNIT 3
an electromagnet and the current. electromagnet and the number of turns of solenoid.
UNIT 3
Pemboleh ubah dimanipulasi: / Manipulated variable: Pemboleh ubah dimanipulasi: / Manipulated variable:
Arus / Current Bilangan lilitan solenoid / The number of turns of solenoid

Pemboleh ubah bergerak balas: / Responding variable: Pemboleh ubah bergerak balas: / Responding variable:
Pemboleh Bilangan paku yang terlekat kepada elektromagnet Bilangan paku yang terlekat kepada elektromagnet
ubah
Variables The number of nails attached to the electromagnet The number of nails attached to the electromagnet
Pemboleh ubah dimalarkan: / Constant variable: Pemboleh ubah dimalarkan: / Constant variable:
Bilangan lilitan solenoid, jenis teras Arus, jenis teras / Current, type of core
The number of turns of solenoid, type of the core

Ammeter, wayar penyambung, reostat, kaki retort, Ammeter, wayar penyambung, reostat, kaki retort, suis,
Senarai bahan suis, bekalan kuasa a.t., teras besi lembut, solenoid, bekalan kuasa a.t., teras besi lembut, solenoid, paku besi
dan radas
List of paku besi kecil dan bekas plastik. kecil dan bekas plastik.
Ammeter, connection wires, rheostat, retort stand, switch, d.c.
Ammeter, connection wires, rheostat, retort stand, switch,
materials and
apparatus d.c. supply, soft iron core, solenoid, small iron nails and supply, soft iron core, solenoid, small iron nails and plastic
plastic container. container.

Solenoid Solenoid
Solenoid Solenoid
Teras besi Teras besi
Susunan lembut lembut
Soft iron
Soft iron
radas core core
Arrangement
of the Paku besi Paku besi
apparatus kecil } H Bekas kecil } H Bekas
Small iron plastik Small iron plastik
nails Plastic nails Plastic
container container
