010039
Handrails extend 12” beyond step to
conform to ADA construction requirements. Clinical Equipment
013241 011219
Unique training staircase device allows
the therapist to train patients on (3)
progressive step levels, 4”, 6” and 8” high steps.

010207
Sets up and coverts easily in straightline
or 90 degree corner arrangement.
010209
Curbs nest under ramp for storage.

ADA Straight Staircase Bariatric & ADA Two-Sided Staircase
– More compact footprint takes up less oor space and ts in conventional 8’ high – Natural Oak high pressure laminated reinforced plywood construction for 750 lb.
. g n i l i e c . y t i c a p a c t h g i e w t n e i t a P
– A.D.A. 11” deep steps x 36” wide have “anti-slip” safety treads. – (2) 6” high x 11” deep steps on one side and (3) 4” high x 11” deeps steps on the
– (3) 6” high steps on one end. other side.
– Platform is 36” x 36” x 18” high. – Solid laminated plywood side panels with ergonomic easy-to-grip hardwood
– Handrails and handrail supports are satin nish premium hardwood and shipped handrails.
ready to bolt on. Length Width Height
– Handrails are designed for ergonomic comfort and have 12” A.D.A. overhang on each 010039 84” 40” 46”
end.
– Overall straight-line set-up.
Length Width Height Convertible Staircases
013241 58” 36” 18” – (4) 6” high steps on one end and (6) 4” high steps on the other end.
– Steps are 36” wide.
– Platform dimensions: 36” x 36” x 24”
3-In-1 Training Staircase – Shipped in two assembled sections
– (6) 4” high steps on one end, (4) 6” high steps on the other end and (3) 8” high steps – Requires minimum of 9’ ceiling.
at front side. – 90 degree corner arrangement dimensions: 64” to 82”
– Handrail for 8” stair section is easily removable and locks into place. Straightline Arrangement Width Depth Height
– Steps are 36” wide. 010207 109” 36” 24”
– Platform dimensions: 36” x 36”
– Requires minimum of 9’ ceiling.
Ramp And Curb Set
U.S. Patent D,428,629 Width Depth Height
011219 109” 56” 24” – Facilitates ambulation and patient mobility training on ramp and curbs
– Ramp elevates from 1/4” to 8” high over its 44” incline
– Flat platform is 44” x 44”
– Unit includes (3) curbs of 2”, 4” and 6” height.
Nested Dimensions Width Depth Height
010209 88” 44” 8”

This is a representation of the products we oer. If you don’t nd what you need on these pages please ask us about it. | 113
